4-2
IM DL350E-17EN
4.1 List of Commands
Command Function page
:ANALysis:HARMonic:LRMS<x1>:RES
ult:RHDFk<x2>?
Queries the percentage content of each harmonic of harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x>:RESu
lt:RMS?
Queries all rms values of harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x1>:RES
ult:RMSK<x2>?
Queries the rms value of each harmonic of harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x>:RESu
lt:THDCsa?
Queries the total distortion (CSA) of harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x>:RESu
lt:THDIec?
Queries the total distortion (IEC) of harmonic RMS analysis. 4-34
:ANALysis:HARMonic:LRMS<x>:SOUR
ce
Sets or queries source channel of harmonic RMS analysis. 4-35
:ANALysis:HARMonic:MODE
Sets or queries the harmonic analysis mode. 4-35
:ANALysis:HARMonic:POSition
Sets or queries the analysis start position of harmonic analysis. 4-35
:ANALysis:HARMonic:POWer
Queries all harmonic power analysis settings. 4-35
:ANALysis:HARMonic:POWer:FSOur
ce
Sets or queries the frequency detection source of harmonic power analysis. 4-35
:ANALysis:HARMonic:POWer:HYSTer
esis
Sets or queries the frequency detection hysteresis of harmonic power
analysis.
4-35
:ANALysis:HARMonic:POWer:MODE
Sets or queries the computation mode of harmonic power analysis. 4-35
:ANALysis:HARMonic:POWer:RESu
lt?
Queries all analysis results related to harmonic power analysis. 4-35
:ANALysis:HARMonic:POWer:RESult
:FREQuency?
Queries the fundamental frequency of harmonic power analysis. 4-35
:ANALysis:HARMonic:POWer:RESult
:LAMBda?
Queries the power factor of harmonic power analysis. 4-35
:ANALysis:HARMonic:POWer:RESult
:P?
Queries the total active power of harmonic power analysis. 4-35
:ANALysis:HARMonic:POWer:RESult
:PHDFk<x>?
Queries the active power percentage content of each harmonic of harmonic
power analysis.
4-35
:ANALysis:HARMonic:POWer:RESult
:PK<x>?
Queries the active power of each harmonic of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:RESult
:PPHik<x>?
Queries the power phase angle of each harmonic of harmonic power
analysis.
4-36
:ANALysis:HARMonic:POWer:RESult
:Q?
Queries the total reactive power of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:RESult
:RI1?
Queries the rms value of I1 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:RESult
:RI2?
Queries the rms value of I2 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:RESult
:RU1?
Queries the rms value of U1 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:RESult
:RU2?
Queries the rms value of U2 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:RESult
:S?
Queries all apparent powers of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:SOUR
ce?
Queries all source channel settings of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:SOURce
:I1
Sets or queries source channel I1 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:SOURce
:I2
Sets or queries source channel I2 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:SOURce
:U1
Sets or queries source channel U1 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:SOURce
:U2
Sets or queries source channel U2 of harmonic power analysis. 4-36
:ANALysis:HARMonic:POWer:WIRing
Sets or queries the wiring system of harmonic power analysis. 4-37
ASETup Group
:ASETup:EXECute
Executes auto setup. 4-38
