4-3
IM DL350E-17EN
Commands
4
4.1 List of Commands
Command Function page
CALibrate Group
:CALibrate?
Queries all calibration settings. 4-39
:CALibrate[:EXECute]
Executes calibration. 4-39
:CALibrate:MODE
Sets or queries the auto calibration mode. 4-39
:CALibrate:SBOCancel:CHANnel<
x>[:STATus] (Strain Balance &
Offset Cancel)
Sets or queries whether the specified channel is included in the balancing of
all channels on strain modules or the DC offset canceling of all channels on
voltage measurement modules.
4-39
:CALibrate:SBOCancel:CHANnel<x1
>:SCHannel<x2>[:STATus] (Strain
Balance & Offset Cancel)
Sets or queries whether the specified 4-CH module’s channel is included in
the balancing of all channels on strain modules or the DC offset canceling of
all channels on voltage measurement modules.
4-39
:CALibrate:SBOCancel:EXECute
(Strain Balance & Offset Cancel)
Executes the strain balancing of all channels on strain modules or the DC
offset canceling of all channels on voltage measurement modules.
4-39
CHANnel Group
:CHANnel<x>?
Queries all vertical axis settings of a channel. 4-40
:CHANnel<x>:ACCL?
Queries all acceleration/voltage module settings. 4-40
:CHANnel<x>:ACCL:BIAS
Sets or queries whether the bias current supply to the acceleration sensors
of an acceleration/voltage module is on.
4-40
:CHANnel<x>:ACCL:BWIDth
Sets or queries the filter when the coupling of an acceleration/voltage
module is set to acceleration.
4-40
:CHANnel<x>:ACCL:COUPling
Sets or queries the input coupling setting of an acceleration/voltage module. 4-40
:CHANnel<x>:ACCL:GAIN
Sets or queries the gain when the coupling of an acceleration/voltage
module is set to acceleration.
4-40
:CHANnel<x>:ACCL:POSition
Sets or queries the vertical position when the coupling of an acceleration/
voltage module is set to acceleration.
4-40
:CHANnel<x>:ACCL:SCALe
Sets or queries the upper and lower limits of the screen when the coupling of
an acceleration/voltage module is set to acceleration.
4-40
:CHANnel<x>:ACCL:SENSitivity
Sets or queries the sensitivity when the coupling of an acceleration/voltage
module is set to acceleration.
4-40
:CHANnel<x>:ACCL:UNIT
Sets or queries the unit string when the coupling of an acceleration/voltage
module is set to acceleration.
4-41
:CHANnel<x>:ACCL:VARiable
Sets or queries the scale setting mode when the coupling of an acceleration/
voltage module is set to acceleration.
4-41
:CHANnel<x>:ACCL:ZOOM
Sets or queries the vertical zoom factor when the coupling of an acceleration/
voltage module is set to acceleration.
4-41
:CHANnel<x>:CAN?
Queries all settings of a module that can monitor CAN bus signals. 4-41
:CHANnel<x>:CAN:OSOut?
Queries all one-shot output settings of the specified port of a module that
can monitor CAN bus signals.
4-41
:CHANnel<x1>:CAN:OSOut:DATA<x2>
Sets or queries the one-shot output data of the specified port of a module
that can monitor CAN bus signals.
4-41
:CHANnel<x>:CAN:OSOut:DLC (Data
Length Code)
Sets or queries the one-shot output data length of the specified port of a
module that can monitor CAN bus signals.
4-41
:CHANnel<x>:CAN:OSOut:EXECute
(One Shot Out)
Executes a one-shot output from a module that can monitor CAN bus
signals.
4-42
:CHANnel<x>:CAN:OSOut:FRAMe
Sets or queries the frame type of one-shot output data of the specified port
of a module that can monitor CAN bus signals.
4-42
:CHANnel<x>:CAN:OSOut:MFORmat
(Message Format)
Sets or queries the frame message format of one-shot output data of the
specified port of a module that can monitor CAN bus signals.
4-42
:CHANnel<x>:CAN:OSOut:MID
(Message ID)
Sets or queries the frame message ID of one-shot output data of the
specified port of a module that can monitor CAN bus signals.
4-42
:CHANnel<x>:CAN:OSOut:MTYPe
(Message Type)
Sets or queries the frame message type (CAN/CAN FD) of one-shot output
data of the specified sub channel on a module that can monitor a CAN bus.
4-42
:CHANnel<x>:CAN:PORT?
Queries all settings of the specified port of a module that can monitor CAN
bus signals.
4-42
:CHANnel<x>:CAN:PORT:BRATe
Sets or queries the bit rate of the specified CAN bus signal port. 4-43
:CHANnel<x>:CAN:PORT:BSNum (Bit
sample num)
Sets or queries the number of sample points of each bit of the specified CAN
bus signal port.
4-43
:CHANnel<x>:CAN:PORT:DBRate
(Data BitRate (CAN FD))
Sets or queries the data bit rate (CAN FD) of the specified CAN bus signal
port.
4-43
:CHANnel<x>:CAN:PORT:DSPoint
(Sample Point (CAN FD))
Sets or queries the sample point (CAN FD) of each bit of the specified CAN
bus signal port.
4-43
