4-4
IM DL350E-17EN
4.1 List of Commands
Command Function page
:CHANnel<x>:CAN:PORT:FDSTandard
(FD Standard (CAN FD))
Sets or queries the protocol type (ISO/non ISO) of the specified CAN bus
signal port.
4-43
:CHANnel<x>:CAN:PORT:LONLy
Sets or queries the listen-only (Listen Only) setting of the specified port of a
module that can monitor CAN bus signals.
4-44
:CHANnel<x>:CAN:PORT:SJW (Sync
jump width)
Sets or queries the resynchronization jump width (Sync Jump Width) setting
of the specified port of a module that can monitor CAN bus signals.
4-44
:CHANnel<x>:CAN:PORT:SPOint
(Sample Point)
Sets or queries the sample point of each bit of the specified CAN bus signal
port.
4-44
:CHANnel<x>:CAN:PORT:TERMinator
Setsorquerieswhethertoturnonthe120ΩterminatorbetweenCAN_H
andCAN_LontheCANbusline.
4-44
:CHANnel<x1>:CAN:SCHannel<x2>?
Queries all settings of the specified sub channel on a module that can
monitor CAN bus signals.
4-44
:CHANnel<x1>:CAN:SCHannel<x2>:B
COunt (Byte Count)
Sets or queries the byte count of the specified sub channel on a module that
can monitor a CAN bus.
4-45
:CHANnel<x1>:CAN:SCHannel<x2>:B
ICount (Bit Count)
Sets or queries the bit length of the data to be extracted of the specified sub
channel on a module that can monitor CAN bus signals.
4-45
:CHANnel<x1>:CAN:SCHannel<x2>:B
LABel<x3>
Sets or queries the specified bit label when the data type of the specified sub
channel on a module that can monitor CAN bus signals is logic.
4-45
:CHANnel<x1>:CAN:SCHannel<x2>:B
ORDer (Byte Order)
Sets or queries the method (endian) to use to store in the internal memory
the data of the specified sub channel on a module that can monitor CAN bus
signals.
4-45
:CHANnel<x1>:CAN:SCHannel<x2>:F
ACTor
Sets or queries the scaling coefficient (the value per bit) of the specified sub
channel on a module that can monitor CAN bus signals.
4-46
:CHANnel<x1>:CAN:SCHannel<x2>:I
NPut
Sets or queries the input ON/OFF state of the specified sub channel on a
module that can monitor CAN bus signals.
4-46
:CHANnel<x1>:CAN:SCHannel<x2>:L
ABel
Sets or queries the label string of the specified sub channel on a module that
can monitor CAN bus signals.
4-46
:CHANnel<x1>:CAN:SCHannel<x2>:M
FORmat
Sets or queries the message format of the specified sub channel on a
module that can monitor CAN bus signals.
4-46
:CHANnel<x1>:CAN:SCHannel<x2>:M
ID
Sets or queries the message ID of the specified sub channel on a module
that can monitor CAN bus signals.
4-46
:CHANnel<x1>:CAN:SCHannel<x2>:O
FFSet
Sets or queries the scaling coefficient (the offset) of the specified sub
channel on a module that can monitor CAN bus signals.
4-47
:CHANnel<x1>:CAN:SCHannel<x2>:P
OSition
Sets or queries the vertical position value of the specified sub channel on a
module that can monitor CAN bus signals.
4-47
:CHANnel<x1>:CAN:SCHannel<x2>:S
BIT (Start BIT)
Sets or queries the bit number of the start position of the specified sub
channel on a module that can monitor a CAN bus.
4-47
:CHANnel<x1>:CAN:SCHannel<x2>:S
CALe
Sets or queries the scale using upper and lower limits of the specified sub
channel on a module that can monitor CAN bus signals.
4-47
:CHANnel<x1>:CAN:SCHannel<x2>:U
NIT
Sets or queries the data unit string of the specified sub channel on a module
that can monitor CAN bus signals.
4-48
:CHANnel<x1>:CAN:SCHannel<x2>:V
TYPe (Value Type)
Sets or queries the data type of the specified sub channel on a module that
can monitor CAN bus signals.
4-48
:CHANnel<x1>:CAN:SCHannel<x2>:Z
OOM
Sets or queries the vertical zoom factor of logic waveforms on a module that
can monitor CAN bus signals.
4-48
:CHANnel<x>:DISPlay
Sets or queries whether the channel is displayed. 4-48
:CHANnel<x>:FREQ?
Queries all frequency module settings. 4-49
:CHANnel<x>:FREQ:INPut?
Queries all frequency module input settings. 4-49
:CHANnel<x>:FREQ:INPut:BWIDth
Sets or queries the input signal bandwidth limit of a frequency module. 4-49
:CHANnel<x>:FREQ:INPut:CELimina
tion
Sets or queries the input signal chattering elimination of a frequency module. 4-49
:CHANnel<x>:FREQ:INPut:COUPling
Sets or queries the input coupling setting of a frequency module. 4-49
:CHANnel<x>:FREQ:INPut:HYSTeres
is
Sets or queries the hysteresis of a frequency module. 4-49
:CHANnel<x>:FREQ:INPut:PRESet
Sets or queries the preset setting of a frequency module. 4-49
:CHANnel<x>:FREQ:INPut:PROBe
Sets or queries the probe attenuation of a frequency module. 4-49
:CHANnel<x>:FREQ:INPut:PULLup
Sets or queries whether pull-up is turned on for a frequency module. 4-49
:CHANnel<x>:FREQ:INPut:SLOPe
Sets or queries the input slope of a frequency module. 4-50
:CHANnel<x>:FREQ:INPut:THResho
ld
Sets or queries the threshold level of a frequency module. 4-50
:CHANnel<x>:FREQ:INPut:VRANge
Sets or queries the voltage range of a frequency module. 4-50
:CHANnel<x>:FREQ:LSCale?
Queries all the linear scaling settings of a frequency module. 4-50
:CHANnel<x>:FREQ:LSCale:AVALue
Sets or queries the scaling coefficient A that is used during linear scaling for
a frequency module.
4-50
