4-5
IM DL350E-17EN
Commands
4
4.1 List of Commands
Command Function page
:CHANnel<x>:FREQ:LSCale:BVALue
Sets or queries the scaling coefficient B that is used during linear scaling for
a frequency module.
4-50
:CHANnel<x>:FREQ:LSCale:GETMeas
ure
Executes the measurement of the linear scaling P1:X or P2:X value of a
frequency module.
4-50
:CHANnel<x>:FREQ:LSCale:MODE
Sets or queries the linear scaling function of the frequency module. 4-51
:CHANnel<x>:FREQ:LSCale:{P1X|P1
Y|P2X|P2Y}
Sets or queries the linear scaling P1:X, P1:Y, P2:X, or P2:Y value of a
frequency module.
4-51
:CHANnel<x>:FREQ:LSCale:UNIT
Sets or queries the unit string for linear scaling of the frequency module. 4-51
:CHANnel<x>:FREQ:OFFSet
Sets or queries the offset of a frequency module. 4-51
:CHANnel<x>:FREQ:POSition
Sets or queries the vertical position for a frequency module. 4-51
:CHANnel<x>:FREQ:SCALe
Sets or queries the upper and lower limits of the screen for a frequency
module.
4-51
:CHANnel<x>:FREQ:SETup?
Queries all the FV settings of a frequency module. 4-52
:CHANnel<x>:FREQ:SETup:CFRequen
cy
Sets or queries the center frequency when measuring the power frequency
on a frequency module.
4-52
:CHANnel<x>:FREQ:SETup:DECelera
tion
Sets or queries whether deceleration prediction is turned on for a frequency
module.
4-52
:CHANnel<x>:FREQ:SETup:DPULse
Sets or queries the distance per pulse when measuring velocity on a
frequency module.
4-52
:CHANnel<x>:FREQ:SETup:FILTer?
Queries all the filter settings of a frequency module. 4-52
:CHANnel<x>:FREQ:SETup:FILTer:P
AVerage?
Queries all the pulse averaging settings of a frequency module. 4-52
:CHANnel<x>:FREQ:SETup:FILTer:P
AVerage:MODE
Sets or queries whether pulse averaging is turned on for a frequency
module.
4-52
:CHANnel<x>:FREQ:SETup:FILTer:P
AVerage:VALue
Sets or queries the number of pulses to average over for a frequency
module.
4-52
:CHANnel<x>:FREQ:SETup:FILTer:S
MOothing?
Queries all the smoothing settings of a frequency module. 4-52
:CHANnel<x>:FREQ:SETup:FILTer:S
MOothing:MODE
Sets or queries whether smoothing is turned on for a frequency module. 4-53
:CHANnel<x>:FREQ:SETup:FILTer:S
MOothing:VALue
Sets or queries the moving average order of smoothing of a frequency
module.
4-53
:CHANnel<x>:FREQ:SETup:FUNCtion
Sets or queries the measurement mode of a frequency module. 4-53
:CHANnel<x>:FREQ:SETup:LRESet
Sets or queries the over-limit reset when performing integration
measurement on a frequency module.
4-53
:CHANnel<x>:FREQ:SETup:MPULse
Sets or queries the positive/negative setting when measuring pulse width on
a frequency module.
4-53
:CHANnel<x>:FREQ:SETup:PROTate
Sets or queries the number of pulses per rotation when measuring
revolutions on a frequency module.
4-54
:CHANnel<x>:FREQ:SETup:RESet
Resets the pulse count when performing integration measurement on a
frequency module.
4-54
:CHANnel<x>:FREQ:SETup:STOPpred
ict
Sets or queries whether stop prediction is turned on for a frequency module. 4-54
:CHANnel<x>:FREQ:SETup:TIMeout
Sets or queries the duty timeout period of a frequency module. 4-54
:CHANnel<x>:FREQ:SETup:TUNit
Sets or queries the time unit (when measuring velocity) of a frequency
module.
4-54
:CHANnel<x>:FREQ:SETup:UNIT
Sets or queries the pulse integration unit of a frequency module. 4-54
:CHANnel<x>:FREQ:SETup:UPULse
Sets or queries the unit/pulse setting of a frequency module. 4-54
:CHANnel<x>:FREQ:SETup:VUNit
Sets or queries the velocity unit of a frequency module. 4-54
:CHANnel<x>:FREQ:VARiable
Sets or queries the scale setting mode of a frequency module. 4-54
:CHANnel<x>:FREQ:VDIV
Sets or queries the Value/Div setting of a frequency module. 4-55
:CHANnel<x>:FREQ:ZOOM
Sets or queries the vertical zoom factor of a frequency module. 4-55
:CHANnel<x>:LABel
Sets or queries the waveform label of a channel. 4-55
:CHANnel<x>:LIN?
Queries all settings of a module that can monitor LIN bus signals. 4-55
:CHANnel<x1>:LIN:FRAMe<x2>?
Queries all LIN bus signal frame settings. 4-55
:CHANnel<x1>:LIN:FRAMe<x2>:CHEC
ksum
Sets or queries the checksum mode of LIN bus signal frames. 4-55
:CHANnel<x1>:LIN:FRAMe<x2>:DLEN
gth
Sets or queries the data length of LIN bus signal frames. 4-55
:CHANnel<x>:LIN:PORT?
Queries all settings of the specified port of a module that can monitor LIN
bus signals.
4-55
:CHANnel<x>:LIN:PORT:BRATe
Sets or queries the bit rate of the specified LIN bus signal port. 4-56
:CHANnel<x1>:LIN:SCHannel<x2>?
Queries all settings of the specified sub channel on a module that can
monitor LIN bus signals.
4-56
To Next Page
