4-6
IM DL350E-17EN
4.1 List of Commands
Command Function page
:CHANnel<x1>:LIN:SCHannel<x2>:B
ICount (Bit Count)
Sets or queries the bit length to be extracted of the specified sub channel on
a module that can monitor LIN bus signals.
4-56
:CHANnel<x1>:LIN:SCHannel<x2>:B
LABel<x3>
Sets or queries the specified bit label when the data type of the specified sub
channel on a module that can monitor LIN bus signals is logic.
4-56
:CHANnel<x1>:LIN:SCHannel<x2>:B
ORDer (Byte Order)
Sets or queries the method (endian) to use to store in the internal memory
the data of the specified sub channel on a module that can monitor LIN bus
signals.
4-56
:CHANnel<x1>:LIN:SCHannel<x2>:F
ACTor
Sets or queries the scaling coefficient (the value per bit) of the specified sub
channel on a module that can monitor LIN bus signals.
4-57
:CHANnel<x1>:LIN:SCHannel<x2>:
ID
Sets or queries the frame ID of the specified sub channel on a module that
can monitor LIN bus signals.
4-57
:CHANnel<x1>:LIN:SCHannel<x2>:I
NPut
Sets or queries the input ON/OFF state of the specified sub channel on a
module that can monitor LIN bus signals.
4-57
:CHANnel<x1>:LIN:SCHannel<x2>:L
ABel
Sets or queries the label string of the specified sub channel on a module that
can monitor LIN bus signals.
4-57
:CHANnel<x1>:LIN:SCHannel<x2>:O
FFSet
Sets or queries the scaling coefficient (the offset) of the specified sub
channel on a module that can monitor LIN bus signals.
4-57
:CHANnel<x1>:LIN:SCHannel<x2>:P
OSition
Sets or queries the vertical position value of the specified sub channel on a
module that can monitor LIN bus signals.
4-57
:CHANnel<x1>:LIN:SCHannel<x2>:S
BIT (Start Bit)
Sets or queries the bit number of the extraction start position of the specified
sub channel on a module that can monitor LIN bus signals.
4-58
:CHANnel<x1>:LIN:SCHannel<x2>:S
CALe
Sets or queries the scale using upper and lower limits of the specified sub
channel on a module that can monitor LIN bus signals.
4-58
:CHANnel<x1>:LIN:SCHannel<x2>:U
NIT
Sets or queries the data unit of the specified sub channel on a module that
can monitor LIN bus signals.
4-58
:CHANnel<x1>:LIN:SCHannel<x2>:V
TYPe (Value Type)
Sets or queries the data type of the specified sub channel on a module that
can monitor LIN bus signals.
4-58
:CHANnel<x1>:LIN:SCHannel<x2>:Z
OOM
Sets or queries the vertical zoom factor of logic waveforms on a module that
can monitor LIN bus signals.
4-58
:CHANnel<x>:LOGic?
Queries all settings of a logic input module. 4-59
:CHANnel<x>:LOGic:{BIT1|...|B
IT8}?
Queries all settings of each bit of a logic input module. 4-59
:CHANnel<x>:LOGic:{BIT1|...|BIT
8}:CELimination
Sets or queries the chattering elimination for the specified bit of the specified
logic channel.
4-59
:CHANnel<x>:LOGic:{BIT1|...|BIT
8}:DISPlay
Sets or queries whether the display of each bit is turned on for the specified
logic channel.
4-59
:CHANnel<x>:LOGic:{BIT1|...|BIT
8}:LABel
Sets or queries the label of each bit for the specified logic channel. 4-59
:CHANnel<x>:LOGic:BMAPping
Sets or queries the bit display method of the specified logic channel. 4-59
:CHANnel<x>:LOGic:POSition
Sets or queries the vertical position of the specified logic channel. 4-59
:CHANnel<x>:LOGic:ZOOM
Sets or queries the vertical zoom factor of a logic input module. 4-59
:CHANnel<x>:MODUle?
Queries the module that is installed in the channel. 4-60
:CHANnel<x>:SENT?
Queries all settings of an SENT monitor module. 4-60
:CHANnel<x>:SENT:FORMat?
Queries all SENT signal message format settings of an SENT monitor
module.
4-60
:CHANnel<x>:SENT:FORMat:CTICk
(Clock Tick)
Sets or queries the clock tick of a SENT signal. 4-60
:CHANnel<x>:SENT:FORMat:CTYPe
(CRC Type)
Sets or queries the CRC type of a SENT signal. 4-60
:CHANnel<x>:SENT:FORMat:DNIBbl
es (Data Nibbles)
Sets or queries the number of data nibbles of a SENT signal. 4-60
:CHANnel<x>:SENT:FORMat:MULTipl
ex
Sets or queries the on/off state of Fast Channel Multiplexing of the SENT
port.
4-61
:CHANnel<x>:SENT:FORMat:PPULse
(Pause Pulse)
Sets or queries whether pause pulses are to be included in FastCH
messages of SENT signals.
4-61
:CHANnel<x>:SENT:FORMat:SCHType
(Slow CH Type)
Sets or queries the Slow CH type of a SENT signal. 4-61
:CHANnel<x>:SENT:ERRor?
Queries all error settings of a SENT monitor module. 4-61
:CHANnel<x>:SENT:ERRor:COUNt?
Queries all error count channel settings of a SENT monitor module. 4-61
:CHANnel<x>:SENT:ERRor:COUNt:FC
RC (Fast Channel CRC)
Sets or queries whether fast channel CRC errors of a SENT signal are to be
integrated in error count channels.
4-61
:CHANnel<x>:SENT:ERRor:COUNt:MR
ESet:EXECute (Manual Reset)
Resets the error count channel value of a SENT signal. 4-61
