4.1 List of Commands
Command Function page
:CHANnel<x>:SENT:ERRor:COUNt:NV
ALue (Nibble Value)
Sets or queries whether nibble value errors of a SENT signal are to be
integrated in error count channels.
4-61
:CHANnel<x>:SENT:ERRor:COUNt:PN
UMber (Pulse Number)
Sets or queries whether pulse number errors of a SENT signal are to be
displayed in error count channels.
4-61
:CHANnel<x>:SENT:ERRor:COUNt:S
CPulse (Succesive Calibration
Pulse)
Sets or queries whether successive calibration pulse errors of a SENT signal
are to be integrated in error count channels.
4-62
:CHANnel<x>:SENT:ERRor:COUNt:SC
RC (Slow Channel CRC)
Sets or queries whether slow channel CRC errors of a SENT signal are to be
integrated in error count channels.
4-62
:CHANnel<x>:SENT:ERRor:COUNt:SR
ESet (Reset on start)
Sets or queries whether the error count channel of a SENT signal is to be
reset at start.
4-62
:CHANnel<x>:SENT:ERRor:DETect?
Queries all error detection settings of a SENT monitor module. 4-62
:CHANnel<x>:SENT:ERRor:DETect:S
CPulse (Successive Calibration
Pulse)
Sets or queries whether successive calibration pulse errors of a SENT signal
are to be detected.
4-62
:CHANnel<x>:SENT:ERRor:TRIGger?
Queries all error trigger channel settings of a SENT monitor module. 4-62
:CHANnel<x>:SENT:ERRor:TRIGger:
FCRC (Fast Channel CRC)
Sets or queries whether fast channel CRC errors of a SENT signal are to be
displayed in error trigger channels.
4-62
:CHANnel<x>:SENT:ERRor:TRIGger:
NVALue (Nibble Value)
Sets or queries whether nibble value errors of a SENT signal are to be
displayed in error trigger channels.
4-62
:CHANnel<x>:SENT:ERRor:TRIGger:
PNUMber (Pulse Number)
Sets or queries whether pulse number errors of a SENT signal are to be
displayed in error trigger channels.
4-63
:CHANnel<x>:SENT:ERRor:TRIGger:
SCPulse (Succesive Calibration
Pulse)
Sets or queries whether successive calibration pulse errors of a SENT signal
are to be displayed in error trigger channels.
4-63
:CHANnel<x>:SENT:ERRor:TRIGger:
SCRC (Slow Channel CRC)
Sets or queries whether slow channel CRC errors of a SENT signal are to be
displayed in error trigger channels.
4-63
:CHANnel<x>:SENT:PROBe
Sets or queries the probe attenuation of a SENT signal channel. 4-63
:CHANnel<x1>:SENT:SCHannel<x2>?
Queries all sub channel settings of a SENT monitor module. 4-63
:CHANnel<x1>:SENT:SCHAnnel<x2>:
BICount (Bit Count)
Sets or queries the bit length of SENT data. 4-63
:CHANnel<x1>:SENT:SCHAnnel<x2>:
BIT<x3>:DISPlay
Sets or queries whether each bit of SENT data is to be displayed. 4-64
:CHANnel<x1>:SENT:SCHAnnel<x2>:
BIT<x3>:LABel
Sets or queries the display label of each bit of SENT data. 4-64
:CHANnel<x1>:SENT:SCHAnnel<x2>:
BORDer (Byte Order)
Sets or queries the endian (byte order) of SENT data. 4-64
:CHANnel<x1>:SENT:SCHAnnel<x2>:
DTYPe
Sets or queries the data type of SENT data. 4-64
:CHANnel<x1>:SENT:SCHAnnel<x2>:
FACTor
Sets or queries the scaling coefficient (value per bit) of SENT data. 4-65
:CHANnel<x1>:SENT:SCHannel<x2>:
INPut
Sets or queries the input on/off state of SENT data. 4-65
:CHANnel<x1>:SENT:SCHAnnel<x2>:
LABel
Sets or queries the display label of SENT data. 4-65
:CHANnel<x1>:SENT:SCHAnnel<x2>:
OFFSet
Sets or queries the offset value of SENT data. 4-65
:CHANnel<x1>:SENT:SCHAnnel<x2>:
POSition
Sets or queries the display position of SENT data. 4-65
:CHANnel<x1>:SENT:SCHAnnel<x2>:
SBIT (Start Bit)
Sets or queries the data extraction position of SENT data. 4-65
:CHANnel<x1>:SENT:SCHAnnel<x2>:
SCALe
Sets or queries the display scale of SENT data. 4-66
:CHANnel<x1>:SENT:SCHAnnel<x2>:
SID (Slow Channel ID)
Sets or queries the Slow CH ID or Fast CH FC of SENT data. 4-66
:CHANnel<x1>:SENT:SCHAnnel<x2>:
UNIT
Sets or queries the unit string of SENT data. 4-66
:CHANnel<x1>:SENT:SCHAnnel<x2>:
VTYPe (Value Type)
Sets or queries the value type of SENT data. 4-66
:CHANnel<x1>:SENT:SCHAnnel<x2>:
ZOOM
Sets or queries the vertical zoom factor of SENT data. 4-66
:CHANnel<x1>:SENT:TIMeout (Time
out)
Sets or queries the timeout period of SENT signals. 4-66
:CHANnel<x>:STRain?
Queries all settings of a strain module. 4-67
