4-60
IM DL350-17EN
:CHANnel<x>:MODUle?
Function Queries the module that is installed in the
channel.
Syntax
:CHANnel<x>:MODUle?
<x> = 1 to 7
Description • The values returned for each module are listed
below.
NOMODULE No module
1
M720250 720250 (HS10M12)
M720268 720268 (HV (with AAF, RMS))
M701261 701261 (UNIVERSAL)
M701262 701262 (UNIVERSAL (AAF))
M701265 701265 (TEMP/HPV)
M720266 720266 (TEMP/HPV)
M701270 701270(STRAIN_NDIS)
M701271 701271(STRAIN_DSUB)
M701275 701275 (ACCL/VOLT)
M720281 720281 (FREQ)
M720211 720211 (HS100M12)
M720220 720220 (16CH VOLT)
M720221 720221 (16CH TEMP/VOLT)
M720230 720230 (LOGIC)
M720240 720240 (CAN)
M720241 720241 (CAN&LIN)
M720242 720242 (CAN/CAN FD)
M720243 720243 (SENT)
M720254 720254 (4CH 1M16)
1 If a 16-CH voltage input module or 16-CH
temperature/voltage input module is installed
and you specify an even channel for <x>,
this command will return “NO MODULE.”
• If <x> is set to 5 or 6, “M720230” will be returned.
• If <x> is set to 7, “GPS” will be returned.
:CHANnel<x>:SENT?
Function Queries all settings of an SENT monitor module.
Syntax
:CHANnel<x>:SENT?
<x> = 1 to 4
:CHANnel<x>:SENT:FORMat?
Function Queries all SENT signal message format settings
of an SENT monitor module.
Syntax
:CHANnel<x>:SENT:FORMat?
<x> = 1 to 4
:CHANnel<x>:SENT:FORMat:CTICk (Clock
Tick)
Function Sets or queries the clock tick of a SENT signal.
Syntax
:CHANnel<x>:SENT:FORMat:
CTICk {<Time>}
:CHANnel<x>:SENT:FORMat:CTICk?
<x> = 1 to 4
<Time> = 1.00us to 100.0us, 0.01 us resolution
Example
:CHANNEL1:SENT:FORMat:CTICK 3.00us
:CHANNEL1:SENT:FORMat:CTICK?
-> :CHANNEL4:SENT:FORMat:CTICK 3.00us
:CHANnel<x>:SENT:FORMat:CTYPe (CRC
Type)
Function Sets or queries the CRC type of a SENT signal.
Syntax
:CHANnel<x>:SENT:FORMat:
CTYPe {LEGacy|RECommended}
:CHANnel<x>:SENT:FORMat:CTYPe?
<x> = 1 to 4
Example
:CHANNEL1:SENT:FORMat:
CTYPE RECOMMENDED
:CHANNEL1:SENT:FORMat:CTYPE?
-> :CHANNEL1:SENT:FORMat:
CTYPE RECOMMENDED
:CHANnel<x>:SENT:FORMat:DNIBbles
(Data Nibbles)
Function Sets or queries the number of data nibbles of a
SENT signal.
Syntax
:CHANnel<x>:SENT:FORMat:
DNIBbles {<NRf>}
:CHANnel<x>:SENT:FORMat:DNIBbles?
<x> = 1 to 4
<NRf> = 1 to 8
Example
:CHANNEL1:SENT:FORMat:DNIBBLES 6
:CHANNEL1:SENT:FORMat:DNIBBLES?
-> :CHANNEL1:SENT:FORMat:DNIBBLES 6
4.6 CHANnel Group
