When the Record Length Is 62.5 M points
(This record length can be selected on DLM4000s with the /M1, /M2, or /M3 option)
IntP: Interpolation Mode
Rep: Repetitive Sampling Mode
Settings
Time/div
When High Resolution mode is off When High Resolution mode is on
When Interleave mode is off* When Interleave mode is on When Interleave mode is off When Interleave mode is on
Realtime IntP/Rep Realtime IntP/Rep Realtime IntP/Rep Realtime IntP/Rep
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
500 s 12.5 k 62.5 M
Interpolation
mode and
repetitive
sampling mode
cannot be
used when you
specify this
record length.
12.5 k 62.5 M
Interpolation
mode and
repetitive
sampling mode
cannot be
used when you
specify this
record length.
When you specify this record length, high resolution mode cannot be
turned on.
200 s 31.25 k 62.5 M 31.25 k 62.5 M
100 s 62.5 k 62.5 M 62.5 k 62.5 M
50 s 125 k 62.5 M 125 k 62.5 M
20 s 312.5 k 62.5 M 312.5 k 62.5 M
10 s 625 k 62.5 M 625 k 62.5 M
5 s 1.25 M 62.5 M 1.25 M 62.5 M
2 s 3.125 M 62.5 M 3.125 M 62.5 M
1 s 6.25 M 62.5 M 6.25 M 62.5 M
500 ms 12.5 M 62.5 M 12.5 M 62.5 M
200 ms 31.25 M 62.5 M 31.25 M 62.5 M
100 ms 62.5 M 62.5 M 62.5 M 62.5 M
50 ms 125 M 62.5 M 125 M 62.5 M
20 ms 312.5 M 62.5 M 312.5 M 62.5 M
10 ms 625 M 62.5 M 625 M 62.5 M
5 ms 1.25 G 62.5 M 1.25 G 62.5 M
2 ms 1.25 G 25 M 2.5 G 50 M
1 ms 1.25 G 12.5 M 2.5 G 25 M
500 μs 1.25 G 6.25 M 2.5 G 12.5 M
200 μs 1.25 G 2.5 M 2.5 G 5 M
100 μs 1.25 G 1.25 M 2.5 G 2.5 M
50 μs 1.25 G 625 k 2.5 G 1.25 M
20 μs 1.25 G 250 k 2.5 G 500 k
10 μs 1.25 G 125 k 2.5 G 250 k
5 μs 1.25 G 62.5 k 2.5 G 125 k
2 μs 1.25 G 25 k 2.5 G 50 k
1 μs 1.25 G 12.5 k 2.5 G 25 k
500 ns 1.25 G 6.25 k 2.5 G 12.5 k
200 ns 1.25 G 2.5 k 2.5 G 5 k
100 ns 1.25 G 1.25 k 2.5 G 2.5 k
50 ns 1.25 G 625 2.5 G 1.25 k
20 ns 1.25 G 250 2.5 G 500
10 ns 1.25 G 125 2.5 G 250
5 ns 1.25 G 62.5 2.5 G 125
2 ns 1.25 G 25 2.5 G 50
1 ns 1.25 G 12.5 2.5 G 25
Acquisition when you specify this record length is performed in single mode.
* On DLM4000s with the /M1 option, with this record length, interleave mode cannot be turned off.
: Roll Mode
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
