6-22

IM DLM4038-03EN

6.12 External Dimensions

Instrument

Unit: mm

Unless otherwise specified, tolerances are ±3% (however, tolerances are ±0.3 mm when below 10

mm).

426

266

13.4 178 23

Rear view

Default Chapter2
Chapter 1 Component Names and Functions18
Chapter 2 Making Preparations for Measurements31
Chapter 3 Common Operations51
Chapter 4 Rear Panel Input and Output68
Chapter 5 Troubleshooting, Maintenance, and Inspection74
- If a Problem Occurs74
- Recommended Part Replacement75
Chapter 6 Specifications76
Appendix98
- Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate99
- Appendix 2 USB Keyboard Key Assignments109
