When the Record Length Is 250 M points
(This record length can be selected on DLM4000s with the /M3 option)
IntP: Interpolation Mode
Rep: Repetitive Sampling Mode
Settings
Time/div
When High Resolution mode is off When High Resolution mode is on
When Interleave mode is off When Interleave mode is on When Interleave mode is off When Interleave mode is on
Realtime IntP/Rep Realtime IntP/Rep Realtime IntP/Rep Realtime IntP/Rep
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
500 s
When you specify this record
length, interleave mode cannot
be turned off.
50 k 250 M
Interpolation
mode and
repetitive
sampling mode
cannot be
used when you
specify this
record length.
When you specify this record length, high resolution mode cannot be
turned on.
200 s 125 k 250 M
100 s 250 k 250 M
50 s 500 k 250 M
20 s 1.25 M 250 M
10 s 2.5 M 250 M
5 s
5 M 250 M
2 s 12.5 M 250 M
1 s 25 M 250 M
500 ms 25 M 125 M
200 ms 125 M 250 M
100 ms 250 M 250 M
50 ms 250 M 125 M
20 ms 1.25 G 250 M
10 ms 1.25 G 125 M
5 ms 2.5 G 125 M
2 ms 2.5 G 50 M
1 ms 2.5 G 25 M
500 μs 2.5 G 12.5 M
200 μs 2.5 G 5 M
100 μs 2.5 G 2.5 M
50 μs 2.5 G 1.25 M
20 μs 2.5 G 500 k
10 μs 2.5 G 250 k
5 μs 2.5 G 125 k
2 μs 2.5 G 50 k
1 μs 2.5 G 25 k
500 ns 2.5 G 12.5 k
200 ns 2.5 G 5 k
100 ns 2.5 G 2.5 k
50 ns 2.5 G 1.25 k
20 ns 2.5 G 500
10 ns 2.5 G 250
5 ns 2.5 G 125
2 ns 2.5 G 50
1 ns 2.5 G 25
Acquisition when you specify this record length is performed in single mode.
: Roll Mode
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
