YOKOGAWA DLM4058 User Manual

App-11
IM DLM4038-03EN
1
2
3
4
5
6
App
Index
Appendix
Appendix 2 USB Keyboard Key Assignments
DLM4000 USB Keyboard
ACQUIRE menu CTRL+A
MATH/REF menu CTRL+B
Execute PRINT CTRL+C
DISPLAY menu CTRL+D
ENHANCED menu CTRL+E
FILE menu CTRL+F
ACTION, GO/NO-GO menu CTRL+G
HISTORY menu CTRL+H
Execute DEFAULT SETUP CTRL+I
Execute AUTO SETUP CTRL+J
ANALYSIS menu CTRL+K
LOGIC(L) menu CTRL+L
LOGIC(A|B), applicable to models with the /L16 option CTRL+SHIFT+l
MEASURE menu CTRL+M
CURSOR menu CTRL+N
SEARCH menu CTRL+O
Set the trigger level to 50% CTRL+P
Execute CLEAR TRACE CTRL+Q
Execute RESET CTRL+R
SHIFT on CTRL+S
TRIGGER MODE menu CTRL+T
UTILITY menu CTRL+U
Set VERTICAL POSITION to 0 div CTRL+V
EDGE menu CTRL+W
ZOOM2 menu CTRL+X
B TRIG menu CTRL+Y
ZOOM1 menu CTRL+Z
CH1 menu CTRL+1
CH2 menu CTRL+2
CH3 menu CTRL+3
CH4 menu CTRL+4
CH5 menu CTRL+5
CH6 menu CTRL+6
CH7 menu CTRL+7
CH8 menu CTRL+8
Execute HELP CTRL+ /
Execute SET CTRL+ENTER
Execute ESC ESC
FFT menu CTRL+SHIFT+B
PRINT MENU menu CTRL+SHIFT+C
X-Y menu CTRL+SHIFT+D
SERIAL BUS menu CTRL+SHIFT+O
Set HORIZONTAL POSITION to 50% CTRL+SHIFT+P
CH UTIL menu CTRL+SHIFT+U
Switch the SCALE knob between FINE mode and 1-2-5 step
mode
CTRL+SHIFT+V
Execute FORCE TRIG CTRL+SHIFT+Y
Switch the ZOOM knob between FINE mode and 1-2-5 step
mode
CTRL+SHIFT+Z or CTRL+SHIFT+X
Select soft key 1 F1
Select soft key 2 F2
Select soft key 3 F3
Select soft key 4 F4
Select soft key 5 F5
Select soft key 6 F6
Select soft key 7 F7
DELAY setup F9
Execute SINGLE F11
Execute RUN/STOP F12
