<8. Parameter Summary>
30
IM 01C22A01-01E
BRAIN Communication Parameter List
Instruments to which applicable:
F: Differential pressure transmitters:
EJA110A, EJA120A, EJA130A, EJA118W, EJA118N, EJA118Y, and EJA115
P: Pressure transmitters: EJA310A, EJA430A, EJA440A, EJA510A, EJA530A, EJA438W, and EJA438N
L: Liquid level transmitters: EJA210A and EJA220A
No. Item Description
Rewrita-
bility
Remarks Default Value
Applicability
FPL
01 MODEL Model+capsule type —
02 TAG NO. Tag number — 16 alphanumerics
03 SELF CHECK Self-diagnostic result — GOOD/ERROR
A DISPLAY Measured data display — Menu name
A10 OUTPUT (%) Output (in %) — –5 to 110%*
3
A11 ENGR. OUTPUT Output (in engineering units) — –19999 to 19999
A20 AMP TEMP Amplifi er temperature — Unit specifi ed in D30
A21 CAPSULE TEMP Capsule temperature — Unit specifi ed in D30
A30 STATIC PRESS Static pressure — Unit specifi ed in D31*
1
—
A40 INPUT Input (indicated as the
value after zeroing)
— –32000 to 32000
A60 SELF CHECK Self-diagnostic
messages
— GOOD/ERROR, CAP MODULE FAULT, AMP
MODULE FAULT, OUT OF RANGE, OUT OF SP
RANGE*
1
, OVER TEMP (CAP),OVER TEMP
(AMP), OVER OUTPUT, OVER DISPLAY, ILLEGAL
LRV, ILLEGAL HRV, ILLEGAL SPAN, and ZERO
ADJ OVER
B SENSOR TYPE Sensor type — Menu name
B10 MODEL Model+span — 16 uppercase alphanumerics
B11 STYLE NO. Style number —
B20 LRL Lower range-limit — –32000 to 32000
B21 URL Upper range-limit — –32000 to 32000
B30 MIN SPAN Minimum span — –32000 to 32000
B40 MAX STAT.P. Maximum static pressure*
6
—
—
B60 SELF CHECK
Self-diagnostic
messages
— Same as A60
C SETTING Setting data — Menu name
C10 TAG. NO. Tag number
16 alphanumerics As specifi ed when
ordered.
C20 PRESS UNIT Measurement range units
Selected from mmH
2
O,
mmAq, mmWG, mmHg,
Torr, Pa, hPa, kPa,MPa,
mbar, bar, gf/cm
2
, kgf/cm
2
,
inH
2
O, inHg, ftH
2
O, psi, or atm
As specifi ed when
ordered.
C21 LOW RANGE Measurement range, lower
range value
–32000 to 32000(but within
measurement range)
As specifi ed when
ordered.
C22 HIGH RANGE Measurement range,
higher range value
–32000 to 32000(but within
measurement range)
As specifi ed when
ordered.
C30 AMP DAMPING Damping time constant
Selected from 0.2*
2
, 0.5, 1.0,
2.0, 4.0, 8.0, 16.0, 32.0, or
64.0 sec.
2.0 s
C40 OUTPUT MODE Output mode and integral
indicator mode
Selected from OUT:LIN; DSP:
LIN, OUT:LIN; DSP:SQR,
OUT:SQR; DSP:SQR
As specifi ed when
ordered.
If not specifi ed,
OUT: LIN; DSP: LIN.
——
C60 SELF CHECK Self-diagnostic messages — Same as A60
D AUX SET 1 Auxiliary setting data 1 — Menu name
D10 LOW CUT Low cut
0.0 to 20.0% 10.0%
D11 LOW CUT MODE Low cut mode
LINEAR/ZERO LINEAR
D15 OUT LIMIT(L) Lower output range-limit
–5.0 to 110.0% –5.0%*
7
D16 OUT LIMIT(H) Lower output range-limit
–5.0 to 110.0% 110.0%
D20 DISP SELECT Display selection
NORMAL %/USER SET, USER
& %/INP PRES, PRES & %
As specifi ed when
ordered.
D21 DISP UNIT Engineering unit for display
8 uppercase alphanumerics
D22 DISP LRV Engineering range, lower
range value
–19999 to 19999 As specifi ed when
ordered.
D23 DISP HRV Engineering range, higher
range value
–19999 to 19999 As specifi ed when
ordered.
To Next Page
