8. Parameter Summary
NOTE
For FOUNDATION Fieldbus and PROFIBUS PA
communication types, please refer to manuals in the
attached CD-ROM.
IMPORTANT
If the transmitter is turned off within 30 seconds after
parameters have been set, the set data will not be
stored and the terminal returns to previous settings.
HART Communication Menu Tree
1 DEVICE SETUP
2 Pres
3 A01 Out
4 LRV
5 URV
Online Menu
1 PROCESS
VARIABLES
2 DIAGNOSTICS
AND SERVICE
3 BASIC SETUP
4 DETAILED
SETUP
5 REVIEW
1 Pressure
2 Percent Range
3 Analog Output
4 Sensor Temperature
5 Static Pressure
6 Engineering Unit
7 Engineering Display
1 TEST/STATUS
2 Loop Test
3 CALIBRATION
1 Self Test
2 Status
1 Keypad Input
2 Wrt protect menu
Hot Key 1 LRV
2 URV
3 Unit
4 LSL
5 USL
6 Min Span
1 Tag
2 Unit
3 RERANGE
4 DEVICE INFO
5 Transfer Function
6 Damp
7 Low Cut
8 Cut Mode
1 Keypad Input
2 Apply Values
1 Date
2 Descriptor
3 Message
4 Write Protect
1 SENSORS
2 SIGNAL
CONDITION
3 OUTPUT
CONDITION
4 DISPLAY
CONDITION
5 DEVICE
INFORMATION
1 Pressure Sensor
2 Temperature
Sensor
3 Static Pressure
Sensor
1 Percent Range
2 Pressure
3 Unit
4 Sensor Trim
1 Zero Trim
2 Pressure
3 Lower Sensor Trim
4 Upper Sensor Trim
5 Sensor Trim Point
6 Clear snsr trim
1 Snsr temp
2 Amp temp
3 Sensor temp Unit
1 Static Pressure
2 Static Pressure Unit
1 PROCESS
VARIABLES
2 RERANGE
3 Unit
4 Transfer Function
5 Damp
6 Low Cut
7 Cut Mode
8 Bi-dir Mode
9 H2O Unit Select
1 PROCESS
VARIABLES
2 ANALOG
OUTPUT
3 Analog Output
Alarm
4 HART OUTPUT
1 Display Mode
2 Display Function
3 Engineering
Display Range
1 Field Device Info
2 Sensor Info
3 Self Test
1 Engineering Unit
2 Engineering Display LRV
3 Engineering Display URV
4 Engineering Display Point
1 Pressure
2 Percent Range
3 Analog Output
4 Sensor Temperature
5 Static Pressure
6 Engineering Unit
7 Engineering Display
1 Loop Test
2 Digital-to-Analog Trim
3 Scaled D/A Trim
4 Auto recover
5 AO lower limit %
6 AO upper limit %
1 Poll Address
2 Number of Request Preambles
3 Burst Mode
4 Burst Option
1 Pressure
2 Percent Range
3 Sensor Temperature
1 Keypad Input
2 Apply Values
1 RERANGE
2 TRIM ANALOG
OUTPUT
3 SENSOR TRIM
1 Keypad Input
2 Apply Values
1 Digital-to-Analog Trim
2 Scaled Digital-to-Analog Trim
1 Zero Trim
2 Pressure
3 Lower Sensor Trim
4 Upper Sensor Trim
5 Sensor Trim Points
6 Clear snsr trim
F0801.ai
1 Write protect
2 Enable wrt 10 min
3 New password
4 Software seal
