1-218
IM 04L51B01-01EN
1.27.2 Supported Commands
The commands supported by the DARWIN compatible communication function are as
follows.
Instantaneous Data Output Commands
Command Description
EF Outputs measured data and math data in binary format.
EL Outputs unit and decimal point information of a specified channel in ASCII
format.
EB Sets the byte output order.
ESC+TCommand
If a “Esc+T” command is received, time-synchronized measured value and math value are
held in the local buffer until the next “Esc+T” command is received.
Command Description
Esc+T Prepares to output the data selected with the TS command.
Setting Commands
Command Description
SR Sets the range.
SN Sets the unit (scale unit).
SA Sets an alarm.
SD Sets the date and time.
SV Sets moving average.
CM Sets math input data (option).
SR Command Parameters
If a setting parameter that the GX/GP does not support is received, a negative response is
returned.
Item Description
Mode RRJC
Range PT2, JPT2, PT2S, JPT2S, GATE
Module AC, STRAIN
CommandsApplicabletoRS-422-A/RS-485Only(Releasenumber2(version2.02)and
later)
Command Description
Esc+O Open Command (address a communication destination)
EXC+C Close Command (close the addressed state of a device)
Data Output Request Commands
Command Parameter Description
TS 0: Measured data Selects the talker output data.
1: Setting parameters
2: Unit information
5: System configuration information
9: Setup mode setting data output
FM 0: Measured data (ASCII) Selects the output format of
measured/math data.
1: Math data (binary)
2: Math data (ASCII)
3: Math channel (binary)
LF — Sets the output channel for the
setting data output, unit, and
decimal place information.
CF — Sets the system configuration data
format.
VF — Relay status output request
BO — Sets the byte output order.
Esc+S
1
— Status byte output command
1 Release number 2 (version 2.02) and later
1.27UsingtheDARWINCompatibleCommunicationFunction(Releasenumber2andlater)
To Next Page
