System Configuration
You can configure a GX/GP system as shown below.
PC
PC
Recorder
Network
printer
Temperature
Controller
Monitor*
Ethernet
USB port*
Alarm output
Serial communication*
RS-232, RS-422/485
FAIL/status output*
keyboard
Mouse
SD memory card
Bar code reader
(GX20/GP20 only)
USB memory
* Option
Manual DO output
Power meter
(WT)
Analog output
DO out
DI input
Alarm out
Control input
DI
RTD
TC/DCV
Control output
A
mA
Pulse
DC loop power
supply
Digital input/output
Signal output
Signal input
DI
RTD
TC/DCV
mA
•
•
•
GX60
Max 6 unit
Pulse
Remote input
GX10
GP20
GP10
• Download PC software
• Download user’s manuals
Web site
GX20
A
3-wire/4-wire
Functional Overview
