YOKOGAWA GX60 - Configuring the Inputs; Starting Measurement and Recording; Switching between Operation Screens

40
IM 04L51B01-02EN
Starting Measurement and Recording
1 Press MENU.
The menu screen appears.
2 Tap the Recording icon.
The record start screen appears.
3 Tap Record.
Recording starts. The recording status icon in the
status display section changes to recording in prog-
ress.
Operation complete
You can also start recording with the START/
STOP key.
You can stop recording in the same way that you
start recording.
Switching between Operation Screens
1 Press MENU.
The menu screen appears.
Trend
Digital
Bar graph
Overview
2 Tap the Browse tab.
3 Tap the icon of the display that you want to change
to.
Operation complete
3 Tap the Time tab.
4 Enter the time using the keyboard, and tap OK.
The time is set.
Operation complete
Configuring the Inputs
For channel 1 (0001) of slot 0, set thermocouple type T, 0
to 200°C.
Path MENU key > Browse tab > Setting >
Setting menu > AI channel settings > Range
1
2
3
4
5
6
7
1 Tap First-CH > 0001.
2 Check that Last-CH is 0001.
3 Tap Type > TC.
4 Tap Range > T.
5 Tap Span Lower, and enter 0.0.
6 Tap Span Upper, and enter 200.0.
7 Tap Save.
Operation complete
Basic Operation
