YOKOGAWA GX60 User Manual

1-2
IM 04L51B01-01EN
Performing Calibration Correction
Item Reference
Performing calibration correction (linearizer approximation, linearizer bias,
correction factor)
→page 1-36
ConfiguringDigitalInputChannels(Settingmenu:DIchannelsettings)
Source module: Digital input module (GX90XD)
Setting the Range
Item Reference
Setting the input range (type, span lower, span upper)
→page 1-40
Performing input calculation (delta, linear scaling)
Setting Alarms
Item Reference
Setting alarms (type, value, hysteresis, logging, output type, alarm delay) →page 1-42
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-44
Setting Display Colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position
Setting the base position and divisions of the bar graph display
Displaying alarm point marks (mark kind, alarm mark color)
Displaying on/off (1/0) signals with characters
ConfiguringPulseInputChannels(Settingmenu:Pulseinputchannelsettings)
Setting the Range
Item Reference
Input range (type, range, chattering filter, span lower, span upper)
→page 1-47Performing input calculations (delta, linear scaling)
Taking the moving average of input values (suppressing noise)
Setting Alarms
Item Reference
Setting alarms (type, value, hysteresis, logging, output, alarm delay) →page 1-49
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-50
Setting display colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position and divisions
Setting the base position and divisions of the bar graph display
Enabling the partial expanded display →page 1-23
→page 1-85
Displaying the color scale band (band area (in, out), color)
→page 1-50
Displaying alarm point marks (mark kind, alarm mark color)
WhatDoYouWanttoConfigure?
