ConfiguringDigitalOutputChannels(Settingmenu:DOchannelsettings)
Source module: Digital output module (GX90YD)
Setting the Range
Item Reference
Setting the range (type, span lower, span upper, unit)
→page 1-54
Setting the action (energize/de-energize, action (and, or, reflash), hold, relay action
on ACK)
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-58
Setting Display Colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position and divisions
Setting the base position and divisions of the bar graph display
Displaying on/off (1/0) states with characters
3. Displaying Measured Data
Measured data acquired in the internal memory can be displayed on the operation screen
as trend waveforms, values, or bar graphs. In addition, in accordance with the application or
the situation at the actual site, measured data can be displayed on a monitor screen (custom
display (/CG option)) that the user designs using DXA170 DAQStudio. A list of alarm
conditions can be displayed.
Trend
Digital
Bar graph
Multi panel
Custom display
WhatDoYouWanttoConfigure?
