Installation Procedure
• Using more than the appropriate
torque to tighten the screws can de-
form the case or damage the brackets.
• Be sure not to insert foreign objects
or tools into the case through the
mounting bracket holes.
• When you attach the rubber pack-
ing, be sure that no portion of it gets
wedged between the GX and the
panel. If the rubber packing is not
attached properly, you will not be able
to achieve sufcient dust proong or
waterproong.
Installation Procedure for the GX10/GX20
Use a steel panel that is 2 mm to 26 mm thick.
1
Insert the GX through the front of the panel.
2
Mount the GX to the panel using the included
mounting brackets as described below.
• Use two mounting brackets to support the top and
bottom or the left and right sides of the case (remove
the stickers that are covering the holes before you
attach the brackets).
• The recommended tightening torque for the mounting
screws is 0.7 to 0.9 N•m.
• Follow the procedure below to mount the GX to the
panel.
• First, attach the two mounting brackets and
temporarily tighten the mounting screws.
• Next, fix the GX in place by tightening the mounting
screws with the appropriate torque. When the GX is
approximately perpendicular to the panel, press the
mounting brackets so that they are in contact with
the case, and fully tighten the mounting screws.
Note
To achieve sufficient dust proofing and waterproofing,
mount the GX in the middle of the panel cut out.
Installation Procedure for the GX60
Use a steel panel that is at least 2 mm thick.
1
Make 6 holes in the panel for the six M4 screws.
2
Fix the unit in place by fastening M4 screws to
the six mounting screw holes. The recommended
tightening torque for the screws is 0.7 to 0.9N•m.
External Dimensions and Panel Cut
Dimensions
GX20 External Dimensions
