YOKOGAWA GX60 - Page 28

24
IM 04L51B01-02EN
GP20 External Dimensions
Unit: mm (approx. inch)
Unless otherwise specified,
tolerance is ±3% (however,
tolerance is ±0.3 mm when
below 10 mm).
*1: With modules
*2: Without modules
(*1)
(*2)
288 (11.34)
196.8 (7.75)
287 (11.30)
( 8 (0.31))
23
(0.91)
MAX 247.2 (9.73)
288 (11.34)
288 (11.34)
( 8 (0.31))
22
(0.87)
GP10 External Dimensions
Unit: mm (approx. inch)
Unless otherwise specified,
tolerance is ±3% (however,
tolerance is ±0.3 mm when
below 10 mm).
*1: With modules
*2: Without modules
(*1)
(*2)
196.8 (7.75)
Max 247.2 (9.73)
144 (5.67)
(8
(0.31)
)
144.9
(5.70)
15
(0.59)
143.6 (5.65)
When using the stand, the GP10 will face 12 degrees
upward.
Installation and Wiring
GX10 External Dimensions
Panel cut dimensions
137
(5.39)
+2
0
175 min.
(6.89)
L
+2
0
L
+2
0
137
(5.39)
+2
0
2
3
4
5
6
7
8
9
10
n
282 (11.10)
426 (16.77)
570 (22.44)
714 (28.11)
858 (33.78)
1002 (39.45)
1146 (45.12)
1290 (50.79)
1434 (56.46)
(144×n)-6
Side-by side mounting
(vertically; max. 3 units)
Side-by-side mounting
(horizontally)
Single-unit
mounting
Units
Unit: mm (approx. inch)
Unless otherwise specified,
tolerance is ±3% (however,
tolerance is ±0.3 mm when
below 10 mm).
137
(5.39)
+2
0
137
(5.39)
+2
0
175 min. (6.89)
L
+2
0
*1: With modules
*2: Without modules
(*1)
(*2)
Panel thickness
(Dimensions before attaching
the mounting bracket)
(Dimensions after attaching
the mounting bracket)
26.6 (1.05)
22.8 (0.90)
2 to 26
157.7 (6.21)
173.1 (6.81)
Max 224.4 (8.83)
136.5
(5.37)
7.5
(0.30)
9.4 (0.37)
136.5
(5.37)
151.5 (5.96)
144 (5.67)
40.9 (1.61)
40.9 (1.61)
103.3
(4.07)
103.3 (4.07)
144 (5.67)
151.5 (5.96)
