YOKOGAWA GX60 - Reconfiguring the GX;GP (Module Identification); Reconfiguring the GX;GP; Initializing the GX;GP (Initializing All Settings)

46
IM 04L51B01-02EN
Initializing the GX/GP
(Initializing all settings)
Initialize the GX/GP after reconfiguring the GX/GP when
channels are not assigned to display groups. Channels
are automatically assigned during initialization.
For details, see the User’s Manual (IM 04L51B01-01EN).
Note
• This procedure is not necessary if you purchased an
I/O module preinstalled model and do not need to
change the configuration.
• If you initialize, setting parameters are reset to their
factory defaults. We recommend that you back up
setting parameters before initialization.
1 Press MENU.
2 Tap the Browse tab.
3 Tap Initialize Calibration > Initialize > Settings/
Inter data.
4 Tap Initialize all > On.
4
5
5 Tap Execute.
A conrmation screen is displayed.
6 Tap OK.
The settings are initialized.
Operation complete
Reconfiguring the GX/GP (Module identification)
Reconfiguring the GX/GP
When you reconfigure the GX/GP and the GX60, the
installed I/O modules are detected, and the settings are
changed accordingly.
Reconfiguration is necessary in the following situations.
• If you specify modules separately
• If you change the modules (change to different modules)
• If you add or remove modules
• If you connect the GX60
• When the measurement mode is changed
• When the advanced security function on/off state is
changed
If you purchased a model with preinstalled modules (/U[]
[]0 or /CR[][] option), you can start using the GX/GP right
away without any reconfiguration. However, if you connect
the GX60, change modules, add modules, or delete
modules, you will need to reconfigure.
Note
You cannot reconfigure GX/GP while recording start
,math start, controled.
1 Press MENU.
2 Tap the Browse tab.
3 Tap Initialize Calibration.
4 Tap Reconfiguration.
5 Tap Execute.
The system information appears.
XX-XX-XX-XX-XX-XX
RX.XX.XX
XXXXXXXXX
6
RX.XX.XX
6 Tap Reconfigure.
7 Tap OK.
Operation complete
Note
Do not carry out the following operations while the GX/
GP is reconfiguring.
• Turn the power off and on
• Insert or remove modules
This procedure is not necessary if you purchased an I/O
module preinstalled model and do not need to change the
configuration.
This section explains what you need to do when you change the module configuration (by installing or removing modules).
