Alarm icon
E-mail transmission is enabled.
Operation lock is enabled.
Math icon (/MT option)
SD memory card icon
Status icon
The condition assigned to instrument information
output is occurring.
Displayed when any alarm is activated.
Alarm activated.
Gray icon: Computation started
Yellow icon: Computation data dropout occurred
Remaining memory space 50% or less
Remaining memory space 10% or less
Remaining memory space 50% or more
External medium error
Lit in red
Blinking in red
Blinking in gray
Alarm indication set to hold. Alarms are
currently activated, and some alarms have not
been acknowledged.
Alarm indication set to hold. All alarms have
been cleared after alarms have occurred, but
some alarms have not been acknowledged.
Displaying the Menu Screen
To change the display between various setup screens and
operation screens, display the menu screen.
1
Press MENU.
The menu screen appears.
MENU key
Tabs
Recording icon
Icons
Scrolls the menu in the tab
(These appear when the number of icons exceeds
the maximum number that can be displayed.)
Setting the Date and Time*
* If you need to set the time zone or DST (Daylight Saving
Time) or both, do so before setting the date and time.
Path MENU key > Browse tab > Setting > Setting
menu > System settings > Time basic
settings
Set the date using the calendar and the time.
Path MENU key > Universal tab > Date/Time
settings
1
Tap the Date tab.
2
Set the month and day with the switch icons.
Switches the year
Switches the month
Time tab
Date tab
Basic Operation
