SettingCommunicationChannels(/MCoption)(Settingmenu:Communication
channelsettings)
Item Reference
Setting communication channels (decimal place, span (upper, lower), unit)
→page 1-136
Replacing values with preset values when communication data is not updated for a
specified time period (watchdog timer function)
Setting Alarms
Item Reference
Setting alarms (type, value, hysteresis, logging, output, alarm delay) →page 1-138
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-139
Setting display colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position and divisions
Setting the base position and divisions of the bar graph display
Enabling the partial expanded display →page 1-139
→page 1-85
Displaying the color scale band (band area (in, out), color)
→page 1-139
Displaying alarm point marks (mark kind, alarm mark color)
10. Miscellaneous
SavingSettingstoExternalStorageMedia(Savesettings)
Item Reference
Saving setting parameters →page 1-196
Saving scale images →page 1-197
Saving report templates (/MT option) →page 1-199
Saving setting parameters, scale images, report templates, and trusted certificates
at once
→page 1-200
Saving trusted certificates →page 1-200
Saving custom displays (/CG option) →page 1-201
LoadingSettingFilesintotheGX/GPfromExternalStorageMedia(Load
settings)
Item Reference
Loading setting parameters →page 1-185
Loading scale images and clearing them from the screen →page 1-187
Loading report templates (/MT option) →page 1-189
Loading setting parameters, scale images, and report templates (/MT option)at
once
→page 1-191
Listing files that are on the external storage medium →page 1-203
Formatting the external storage medium →page 1-204
Initializing,Reconfiguring,andAdjustingtheTouchScreen(Initializationand
reconfiguration)
Item Reference
Initializing the settings and internal memory →page 1-205
Reconfiguring the GX/GP →page 1-207
Adjusting the Touch Screen →page 5-7
