38
IM 04L51B01-02EN
Viewing the Operation Screen (Trend)
Waveform
display
Data display section
Scale
Status display section
Shows the display name, date/time,
data recording, alarm icons, etc.
Shows measured data and function
setup screens
Numeric display section
Status Display Section
Recording stopped
Recording in progress
Date and time
When using the batch function
When using the login function
Data type
DISP: Display data
EVENT: Event data
Recording progress
Internal memory error
Recording status icon
Display name or group name
When using the login and batch functions
Displays the progress using a green bar graph.
The frame indicates the saving interval (display
data) or data length (event data).
Control status icon
Control in
progress
Control
stopped
Basic Operation
Setting and Removing SD Memory
Cards
Setting a SD Memory Card
1 Open the front door.
2 Insert an SD memory card into the card slot.
Removing the SD Memory Card
1 Press MENU.
2 Tap the media eject icon.
3 On the screen for selecting the type of media, tap
SD.
4 Remove the SD memory card.
Operation complete
