YOKOGAWA GX60 - Alarm DO Output; Using the Scaling Function (Measuring a Flow Meter)

43
IM 04L51B01-02EN
Alarm DO output
Alarms are transmitted via DO output to DO channel 1 of
slot 1. (A DO output module is required.)
Configure the following settings in the alarm settings (see
“Setting Alarms”).
1
2
1 Tap Output type > Relay.
2 Tap the Output No., and enter 0101.
Path MENU key > Browse tab > Setting >
Setting menu > DO channel settings > Range
1
2
3
4
1 Tap First-CH > 0101.
2 Check that Last-CH is 0101.
3 Tap Range Type > Alarm.
4 Tap Save.
Operation complete
Using the Scaling Function
(Measuring a flow meter)
On channel 1 of slot 1 (0101), measure the input signal
ranging from 1 to 5 VDC as 0.0 to 100.0 m
3
/h.
Path MENU key > Browse tab > Setting >
Setting menu > AI channel settings > Range
1
2
3
4
5
7
8
9
10
11
6
1 Tap First-CH > 0101.
2 Check that Last-CH is 0101.
3 Tap Type > GS.
4 Tap Range > 1-5V.
5 Tap Calculation > Linear scaling.
6 Drag the screen up.
Show the setting parameters off the screen at the
bottom.
7 Tap Decimal place > 1.
8 Tap Scale Lower, and enter 0.0.
9 Tap Scale Upper, and enter 100.0.
10 Tap Unit, and enter m3/h.
11 Tap Save.
Operation complete
Advanced Operation (Various settings and operation)
