YOKOGAWA GX60 - Setup Menu Map

51
IM 04L51B01-02EN
Setup Menu Map
Depending on setting parameter values, some items may be hidden. For details, see the User’s Manual (IM 04L51B01-01EN).
AI channel settings, AI (mA) channel settings
Range
First-CH
Last-CH
Range
Type
Range
Span Lower
Span Upper
Calculation
Reference channel
Scale
Decimal place
Scale Lower
Scale Upper
Unit
Low-cut
On/Off
Low-cut value
Low-cut output
Moving average
On/Off
Count
First-oder lag filter
2 3
On/Off
Filter coefficient
RJC
1 3
Mode
Temperature
Burnout set
3
Mode
Bias
Value
Alarm
First-CH
Last-CH
Level 1
On/Off
Type
Value
Hysteresis
Logging
Output type
Output No.
Level 2
On/Off
Level 3
On/Off
Level 4
On/Off
Alarm delay
Hour
Minute
Second
Display settings
First-CH
Last-CH
Tag
Characters
No.
Color
Color
Zone
Lower
Upper
Scale
Position
Division
Bar graph
Base position
Division
Partial
On/Off
Expand
Boundary
Color scale band
Band area
Color
Display position Lower
Display position Upper
Alarm point mark
Indicate on Scale
Mark kind
Alarm 1 color
Alarm 2 color
Alarm 3 color
Alarm 4 color
Display characters of
each value
0
1
Calibration correction
First-CH
Last-CH
Mode
Mode
Number of set points
1
Linearizer input
Linearizer output
Execution of input
measurement
:
12
Linearizer input
Linearizer output
Execution of input
measurement
