YOKOGAWA GX60 - Saving and Loading Setting Parameters; Saving Setting Parameters; Loading Setup Parameters

47
IM 04L51B01-02EN
Saving and Loading Setting Parameters
Saving Setting Parameters
Save setting parameters to the SD memory card with the
file name “SF1.”
Path MENU key > Browse tab > Save load
> Menu Save settings > Setting parameters
1
2
3
4
1 Tap Media kind > SD.
2 Tap File name, and enter SF1.
3 Tap Execute.
4 Tap Exit.
Operation complete
This section explains how to back up setting parameters.
Before you change the module configuration or settings, we recommend that you back up the setting parameters.
Loading Setup Parameters
Load the setup parameter file “SF1.GNL” from the SD
memory card.
Path MENU key > Browse tab > Save load
> Menu Load settings > Setting parameters
1
2
3
4
1 Tap Media kind > SD.
2 Tap File name > SF1.GNL.
3 Tap Execute.
4 Tap Exit.
Operation complete
