GX/GP Style Number, Release Number, and
Firmware Version Number
Style number: The GX/GP hardware ID number. This
number is written on the name plate (H
column).
Release number: The GX/GP firmware ID number. This
number is written on the name plate
(S column). This number matches with
the integer part of the firmware version
number.
Example: If the firmware version number is 1.01, the
release number is 1.
Firmware version number:
This number appears on the system
information screen of the GX/GP.
To view the number, see section
2.3, “Displaying Various Types of
Information” in the User’s Manual, IM
04L51B01-01EN.
Conventions Used in This Manual
• This manual covers information regarding GX/GPs
whose display language is English.
•
For details on the language setting, see the Paperless
Recorder User’s Manual, IM04L51B01-01EN.
Unit
K: Denotes 1024. Example: 768K (file size)
k: Denotes 1000.
The notes and cautions in this manual are indicated using
the following symbols.
Improper handling or use can lead to injury to the user or
damage to the instrument. This symbol appears on the
instrument to indicate that the user must refer to the user’s
manual for special instructions. The same symbol appears
in the corresponding place in the user’s manual to identify
those instructions. In the manual, the symbol is used in
conjunction with the word “WARNING” or “CAUTION.”
WARNING
Calls attention to actions or conditions that could cause
serious or fatal injury to the user, and precautions that can
be taken to prevent such occurrences.
CAUTION
Calls attentions to actions or conditions that could cause
light injury to the user or damage to the instrument or
user’s data, and precautions that can be taken to prevent
such occurrences.
Note
Calls attention to information that is important for proper
operation of the instrument.
Module Notation
When necessary, the following notations are used to
distinguish the GX90XA analog input modules by type.
Type Suffix Code Notation
-U2 Universal
-C1 Current (mA)
-L1 Low withstand voltage relay
-T1 Electromagnetic relay
-H0 High-speed universal or High speed AI
-R1 4-wire RTD/resistance
