66
IM 04L51B01-02EN
Segment settings
Program pattern setting
Segment number
Target setpoint
Loop 1
:
Loop 20
Segment time
Time
Segment PID number
selection
Junction code
Time Event settings
Segment number
Time Event 1
Starting condition
On time
Off time
:
Time Event 32
Starting condition
On time
Off time
PV Event settings
Segment number
PV Event 1
Loop number
Type
Value
:
PV Event 32
Loop number
Type
Value
PV Event hysteresis
Hysteresis
PV Event 1
:
PV Event 32
Insert/Delete segment
Segment number
Insert/Delete segment
Execute
Repeat function
settings
Repeat function
settings
Repeat function
Number of repeat
cycles
Repeat cycle start
segment number
Repeat cycle end
segment number
Event display group
Event display 1
Display
Event type
Event number
:
Event display 10
Display
Event type
Event number
Setup Menu Map
