YOKOGAWA GX60 User Manual

2-34
IM 04L51B01-01EN
2.2.8 SwitchingtotheSecondaryTrendInterval
You can switch the trend interval.
To do so, in Display settings, under Trend interval, you need to set Trendrateswitching
to On.
For the setup procedure, see page 1-81 in section 1.7.1, “Setting the Trend Interval”.
You can configure the GX/GP so that a message is written automatically when the trend
interval is changed. To do so, in Display settings, under Trend setting, you need to set
message Change message to On.
For details on the settings, see page 1-85 in section 1.7.4, “Setting Trend Display
Conditions”.
Procedure
1 Press MENU.
The menu screen appears.
2 Tap the Context tab and then DispRate First/Second.
The trend interval switches from First to Second. A message appears in the trend display (if the
function is enabled).
Display example: 10:53 1min/div
Each time you tap DispRate First/Second, the setting toggles between First and
Second.
3 Tap the Close icon to close the menu screen.
Operation complete
Note
Only the displayed time axis changes when you switch to the secondary trend interval. The trend
interval of recording data does not change.
2.2 Configuration of Measured Data Display
