4-42
IM 04L51B01-01EN
•
16-bitSignedInteger
Unit
I/O Channel Data
Hold Register
Data T
ype
GX/GP main unit
Channel 0001 data
402001
16-bit signed integer
|
|
Channel 0050 data
402050
Channel 0101 data
402051
|
|
Channel 0150 data
402100
Channel 0201 data
402101
|
|
Channel 0250 data
402150
Channel 0301 data
402151
|
|
Channel 0350 data
402200
Channel 0401 data
402201
|
|
Channel 0450 data
402250
Channel 0501 data
402251
|
|
Channel 0550 data
402300
Channel 0601 data
402301
|
|
Channel 0650 data
402350
Channel 0701 data
402351
|
|
Channel 0750 data
402400
Channel 0801 data
402401
|
|
Channel 0850 data
402450
Channel 0901 data
402451
|
|
Channel 0950 data
402500
Expandable I/O 1
Channel 1001 data
412001
|
|
Channel 1050 data
412050
Channel 1
101 data
412051
|
|
Channel 1
150 data
412100
Channel 1201 data
412101
|
|
Channel 1250 data
412150
Channel 1301 data
412151
|
|
Channel 1350 data
412200
Channel 1401 data
412201
|
|
Channel 1450 data
412250
Channel 1501 data
412251
|
|
Channel 1550 data
412300
Expandable I/O 2
Channel 2001 data
417001
|
|
Channel 2050 data
417050
Channel 2101 data
417051
|
|
Channel 2150 data
417100
Channel 2201 data
417101
|
|
Channel 2250 data
417150
Channel 2301 data
417151
|
|
Channel 2350 data
417200
Channel 2401 data
417201
|
|
Channel 2450 data
417250
Continued on next page
