Page #446 background image
4-44
IM 04L51B01-01EN
Unit I/O Channel Data Input Register Data Type
Expandable I/O 6 Channel 6201 data 437101 16-bit signed integer
| |
Channel 6250 data 437150
Channel 6301 data 437151
| |
Channel 6350 data 437200
Channel 6401 data 437201
| |
Channel 6450 data 437250
Channel 6501 data 437251
| |
Channel 6550 data 437300
I/O Channel Data Status Information
Unit I/O Channel Data Hold Register Data Type
GX/GP main unit Channel 0001 status information 402501 16-bit signed integer
| |
Channel 0050 status information 402550
Channel 0101 status information 402551
| |
Channel 0150 status information 402600
Channel 0201 status information 402601
| |
Channel 0250 status information 402650
Channel 0301 status information 402651
| |
Channel 0350 status information 402700
Channel 0401 status information 402701
| |
Channel 0450 status information 402750
Channel 0501 status information 402751
| |
Channel 0550 status information 402800
Channel 0601 status information 402801
| |
Channel 0650 status information 402850
Channel 0701 status information 402851
| |
Channel 0750 status information 402900
Channel 0801 status information 402901
| |
Channel 0850 status information 402950
Channel 0901 status information 402951
| |
Channel 0950 status information 403000
Expandable I/O 1 Channel 1001 status information 412501
| |
Channel 1050 status information 412550
Channel 1101 status information 412551
| |
Channel 1150 status information 412600
Channel 1201 status information 412601
| |
Channel 1250 status information 412650
Channel 1301 status information 412651
| |
Channel 1350 status information 412700
Continued on next page
4.5 Modbus Function and Register Assignments
