Kind Inst Inst •••
Min Min •••
Max Max •••
Sampling Data
TTT•••T NNN•••N NNN•••N NNN•••N •••
Massage Data
TTT•••T SSS•••S None SSS•••S
Key
Communication
Remote
Event
System
Serial
NNN•••N: Value
SSS
•••S: Character string
TTT
•••T: Date and time
Common header YREC Fixed character string
Format header Measure Data File type
Model Model name
Language –
Information header section Serial No. Serial number (up to 16 characters)
Time Correction Time change information
Sampling Interval Sampling interval
Trigger Point Trigger point: 0 and higher
Equip Tag Equipment tag (up to 32 characters)
Equip TagNo. Equipment tag number (up to 16 characters)
File Header File header (up to 50 characters)
File ID First: Record start number
Second: File serial number up to record stop
Start Info Start user name (up to 20 characters)
End Info End user name (up to 20 characters)
Extra Data –
Time Zone Current time zone setting
DST Current DST setting
Batch Info Lot number: 0 and higher
Batch number (up to 32 characters)
The entire block is omitted when batch is set to off.
Batch Comment User name (up to 20 characters), comment (up to 50 characters)
Text Info The entire block is omitted when batch is set to off.
Text Field Title (up to 20 characters), text (up to 30 characters)
Table header section Ch Channel number (up to 4 characters)
The character string “Message” is inserted at the right end.
Ch Id Tag number (up to 16 characters, spaces on the right)
Tag Tag name (up to 32 characters, spaces on the right)
Unit Unit name (up to 6 characters, spaces on the right)
Type The character string “Message” is inserted at the right end.
Kind The character string “Count” is inserted at the right end.
Measured data block Sampling Data The number of messages (up to 4 characters) is inserted in the
right most column.
Message data block Massage Data Message string (up to 32 characters), user name (up to 20
characters)
If the number of messages is zero, the entire block is omitted.
For freehand messages, the message string is
“*FreehandMessage*.”
Appendix 3 Text File Data Format
