StandardAccessories
Product Qty
Mountingbracket(forGX10orGX20) 2
SDmemorycard(1GB) 1
Stylus pen (touch pen) 1
Tagsheet(forGX10orGX20) 1
Sheet(paper)(forGX10orGX20) 1
ApplicationSoftware (SoldSeparately)
Model Description OS
DXA170 DAQStudio WindowsVista/7/8/8.1
GA10 DataLoggingSoftware Windows
Vista/7/8.1/10
WindowsServer
2008/2012
*5 /UC40,/UC50,/US40and/US50cannotbespeciedfortheGX10.
*6 /CR20,/CR21,/CR40and/CR41cannotbespeciedfortheGX10.
*7 If/UC20or/US20isspecied,/CR11cannotbespeciedfortheGX10.
*8 If/UC30or/US30isspecied,/CR01,/CR10and/CR11cannotbespeciedfortheGX10.
*9 DigitalinputmodulehaveM3screwterminals.
*10
TheDisplaylanguageisselectablefromEnglish,German,French,Russian,Korean,Chinese,Japanese.(AsofMar.,2013)
 Toconrmthecurrentavailablelanguages,pleasevisitthefollowingwebsite.
URL: http://www.yokogawa.com/ns/language/
*11 Solidstaterelayscannertype(TypeSufxCode:-U2).Ifyouneedtheelectromagneticrelayscannertype,currentscanner
type,L-modelDCV/TC/DI,scannertype,purchaseitseparately.
*12LargememorytypecanbespeciedonlyfortheGX20.
*13ToconnectanexpandableI/O,youwillneedoneexpansionmodulefortheGX.
*14/MCoptionmustbeseparatelyspeciedwhentheWTcommunicationisselected.
*15CreatingcustomdisplaysrequiresDXA170DAQStudio(soldseparately).(GXdoesnothaveacreationfunction.)
*16Optionalcode/MT(MATH)requiredifusingtheGX90XD'sorGX90WD'spulseinput.
*17The/MToption(computation)isrequiredtoperformpulseintegrationonGX90XPpulseinputmodules.
Analoginputmodule,DigitalI/Omodule(soldseparately):
MODELandSUFFIXCode(GX90XA)
MODELandSUFFIXCode(GX90XD)
MODELandSUFFIXCode(GX90YD)
MODELandSUFFIXCode(GX90WD)
MODELandSUFFIXCode(GX90XP)
 PleaseseeGX90XA/GX90XD/GX90YD/GX90WD/GX90XPInput/OutputModuleGeneralSpecication(GS
04L53B01-01EN.)
When connecting the Expandable I/O
 PleaseseeGX60ExpandableI/O,GX90EXExpansionModuleGeneralSpecication(GS04L53B00-01EN.)
 OptionalAccessories(SoldSeparately)
Product Model/partno.
ModelSDmemorycard(1GB) 773001
Mounting bracket B8740DY
Stylus pen (touch pen) B8740BZ
ShuntresisterforM3terminal(10Ω±0.1%)
X010-010-3
ShuntresisterforM3terminal(100Ω±0.1%)
X010-100-3
ShuntresisterforM3terminal(250Ω±0.1%)
X010-250-3
ShuntresisterforClampterminal(10Ω±0.1%)
438922
ShuntresisterforClampterminal(100Ω±0.1%)
438921
ShuntresisterforClampterminal(250Ω±0.1%)
438920
Dummycover B8740CZ
ValidationDocuments(For/ASoption)*1 773230
*1 ProvisionofValidationDocuments
 Alicensesheetcontainingthelicensekey
requiredforinstallationisprovided.
 Downloadthevalidationdocumentfromthe
followingURL.
 http://www.smartdacplus.com/software/en/
