All Rights Reserved. Copyright © 2012, Yokogawa Electric Corporation
GS 04L52B01-01EN Nov. 10, 2015-00
*1 AppliestoGX90XA-10-U2,A/Dintegrationtime
16.67msormore,Generaloperatingconditions:
23±2 ºC, 55±10% RH, supply voltage 90–132,
180–264VAC,supplyfrequencywithin50/60
Hz±1%,warm-upof30minutesormore,no
vibrationsorotherhindrancestoperformance.
*2 Forthemeasuringaccuracy(guaranteed),
seethemodule'sgeneralspecications
(GS04L53B01-01EN).
*3 Thesevaluesdonotincludethereference
junctioncompensationaccuracy.
rdg: reading value
 MAIN UNIT SPECIFICATIONS
■ FUNCTIONALSPECIFICATION
InputSpecications
 PleaseseeGX90XA/GX90XD/GX90YD/GX90WD/
GX90XPI/OModuleGeneralSpecications.
Model Name General
SpecicationNo.
GX90XA Analoginputmodule GS 04L53B01-01EN
GX90DX Digitalinputmodule
GX90YD Digitaloutputmodule
GX90WD
Digitalinput/outputmodule
GX90XP Pulseinputmodule
MeasuringFunctions
• ThenumberofinstallablemodulesandI/O
channels(totalforGPandexpandableI/O)
GP10/GP20-1
Item GP10/GP20-1
Numberofmodule Max.10
Numberofinput/outputmodule Max.100
GP20-2
Item GP20-2
Numberofmodule Max.45
Numberofinput/outputmodule Max.500(ormax.450for
AIonly)
Restrictionsofmoduleconnection:
• Amaximumof10modulescanbeinstalled,as
atotalforGX90YDdigitaloutputmodulesand
GX90WDdigitalI/Omodules.
• AmaximumofoneGX90WDdigitalI/Omodulecan
beinstalledinGPandineachexpandableI/O.
• ExpandableI/Oconnection
 Numberofconnectableunits:Max.6
Caution
 IfthemaximumnumberofI/Ochannelsare
assigned and the last channel is assigned to an
intermediatechannelofamodule,thatmoduleand
subsequentmoduleswillnotberecognized.
1
10
100
81
90
91
Module 1
Module n
:
:
:
• • •
:
Maximum number of I/O channels
DisplayFunctions
Displaygroups:
 Numberofgroups;GP10:30,GP20-1:50,
GP20-2: 60
 Numberofchannelsthatcanbeassignedto
each group; GP10: 10, GP20: 20
Scan interval: 100
*1*2
, 200
*1*2
,500ms
*1
, 1, 2, 5 s
*1 Cannotbespeciedifanelectromagneticrelay
scannertype(TypeSufxCode:-T1)analoginput
moduleisinuse.
*2 CannotbespeciedforL-modelDCV/TC/DI,
scannertype(TypeSufxCode:-L1).
Displaycolor(Trend/Bargraph/Digitaldisplay):
  Channel:Selectfrom24colors
  Adesireddisplaycolorcanbeselectedfreely
using its RGB value.
  Background:Selectfromwhiteorblack
Displaytype:
● Trenddisplay(T-Y)
 Displaymethod:
Direction:Horizontal,vertical
Trend interval: 5
*1*2
, 10
*1*2
, 15
*1
, 30 s/div, 1, 2,
5,10,15,20,30min/div,1,2,4,10h/div
*1 Cannotbespeciedifanelectromagneticrelay
scannertypeanaloginputmoduleisinuse.
*2 CannotbespeciedforL-modelDCV/TC/DI,
scannertype(TypeSufxCode:-L1).
 Trendlinewidth:Thick,normal,thin
 Scale;GP10:Max.6,GP20:Max.10
Current value bar graph, color scale band,
andalarmpointmarkscanbedisplayedon
the scale.
Movingscale;Scalecanbemovedonany
waveform.
Abitmapimagescalecanbeattached.
 Others;Grid(Auto,4to12),Tripline,Message,
Zonedisplay,Partialexpandeddisplay
● Historicaltrenddisplay(T-Ydisplay)
Redisplays the display data or event data in the
internalmemoryorexternalstoragemedium
 Timeaxisoperation:Thetimeaxiscanbe
reducedorexpanded.
 Datasearch:Waveformsfromtheinternal
memorycanbedisplayedthroughthe
specicationofadateandtime,calendar,each
summary
 Movingscale;Abitmapimagescalecanbe
attached.
 Allhistoricaltrendscanbedisplayedinone
screen.
● Bargraphdisplay
 Direction:Verticalorhorizontal
 Scale:Displayascaleforeachchannel
Colorscaleband,andalarmpointmarkscan
be displayed on the scale.
● Digitaldisplay
 Displaysmeasuredvaluesnumerically
 ADIinputstatecanbedisplayedasanarbitrary
characterstring(0=Off/1=On,etc.)
 Updaterate:0.5s
● Overviewdisplay
 Displayformat:Allchannels,eachgroups
 Displaysthemeasuredvaluesofallchannels
andthealarmstatuses
