YOKOGAWA GX60 User Manual

7
All Rights Reserved. Copyright © 2012, Yokogawa Electric Corporation
GS 04L52B01-01EN
Nov. 10, 2015-00
 HARDWARE SPECIFICATIONS
(MAINUNIT)
Display
Displayunit*:
GP10:5.7-inchTFTcolorLCD(640×480dots)
GP20:12.1-inchTFTcolorLCD(800×600dots)
* Asmallnumberofmissingorsteady-onLCD
pixelsandminorvariationsinbrightness
uniformityisanormaldisplaycharacteristicand
notamalfunction.
Touchscreen:
4 wire resistive touch screen
Construction
• Material;
Case: Metal plate
Bezel and display cover: Polycarbonate
• Color;
Case:Smokeblue
Bezel: Charcoal grey light
• Externaldimensions:
Wheninstallingmodules
 GP10:144(W)×168(H)×248(D)mm
  GP20:288(W)×318(H)×248(D)mm
 Whenuninstallingmodules
 GP10:144(W)×168(H)×197(D)mm
  GP20:288(W)×318(H)×197(D)mm
  (D:depthfromthepanelmountingplane)
• Weight:
GP10:Approx.1.9kg,GP20:Approx.5.4kg
(excludingmodules)
PowerSupply
[Powersupplysufxcode:1]
• Ratedsupplyvoltage:100to240VAC
• Allowablepowersupplyvoltagerange:90to132,
180to264VAC
• Ratedpowersupplyfrequency:50/60Hz
• Powerconsumption:
Supply
voltage
LCDbacklight
off
Normal
operation
Maximum
100VAC GP10:16VA
GP20:28VA
GP10:20VA
GP20:34VA
GP10:48VA
GP20:90VA
240VAC GP10:24VA
GP20:38VA
GP10:30VA
GP20:45VA
GP10:60VA
GP20:110VA
* ThefollowingcombinationsareassumedforLCD
backlightoffandnormaloperation.
GP10:1AImodule,1DOmodule,1DImodule
GP20:5AImodules,4DOmodules,1DImodule
• Modulepowersupplyvoltage:Thetotalallowable
powerconsumptionofrespectivemodulesisup
to6WintheGP10andupto20WintheGP20.
• Allowableinterruptiontime:Lessthan1cycleof
thepowersupplyfrequency
[Powersupplysufxcode:2]
• Ratedsupplyvoltage:12VDC
• Allowablepowersupplyvoltagerange:10to20
VDC
• Powerconsumption:
Supply
voltage
LCDbacklight
off
Normal
operation
Maximum
12VDC 7VA 10VA 26VA
Isolation
• Insulationresistance:BetweentheEthernet,
RS-422/485,andeachinsulationterminalsand
earth:20MΩorgreaterat500VDC
• Withstandvoltage:
Betweenthepowerterminalandearth(Incase
ofPowersupplysufxcode:1):3000VACat
50/60Hzforoneminute
 Betweenthepowerterminalandearth(Incase
ofPowersupplysufxcode:2):500VACat
50/60Hzforoneminute
 Betweenthecontactoutputterminalandearth:
3000VACat50/60Hzforoneminute
 Betweentheinput/outputmodulesandearth:
DependsonthespecicationofI/Omodule.
• Grounding:Besuretosetalowgrounding
resistance.
• Isolation:
Power terminal
The circuits divided by lines are insulated mutually.
Internal circuit
FAIL output terminal
Ethernet port
RS-422/485 terminal
Input and output module terminal
Input and output module internal circuit
Earth (PE) terminal
RS-232 terminal
SD card slot
USB port
SafetyandEMCStandards
• CSA:CSA22.2No.61010.1,installation
categoryII(*1),andpollutiondegree2(*2),and
CSA-C22.2NO.61010-2-030-12
• UL:UL61010-1,UL61010-2-030(CSANRTL/C)
• CE:
EMC directive
  EN61326-1compliance,ClassATable2
  EN61000-3-2compliance
  EN61000-3-3compliance
  EN55011ClassAGroup1
Low voltage directive
EN61010-1, EN 61010-2-030
  InstallationcategoryII(*1)
  Pollutiondegree2(*2)
  MeasurementcategoryII(*3)
• C-Tick:EN55011compliance,ClassAGroup1
• KCmarking:Electromagneticwaveinterference
preventionstandard,electromagneticwave
protectionstandardcompliance
*1 Installationcategory(overvoltagecategory)II:
 Describesanumberwhichdenesatransient
overvoltage condition.
 Impliestheregulationforimpulsewithstand
voltage.
 “II”appliestoelectricalequipmentwhich
issuppliedfromthexedinstallationlikea
distribution board.
*2 Pollutiondegree2:
 Describesthedegreetowhichasolid,liquid,
or gas which deteriorates dielectric strength or
surfaceresistivityisadhering.
 “2”appliestonormalindooratmosphere.
Normally,onlynon-conductivepollutionoccurs.
*3 Measurementcategory:Dependsonthe
specicationofeachmodules
