YOKOGAWA PH402G User Manual

Parameter setting 5-25
IM 12B6B3-E-H
Code Display Function Function detail X Y Z Default Values
mA Outputs
30 *mA output signal 0-20 mA on mA1 0 1.1
4-20 mA on mA1 1 mA1 4-20
0-20 mA on mA2 0
4-20 mA on mA2 1 mA2 4-20
31 The choices below appear when pH was selected in service code 01
pH *OUTP.F Output Parameter pH on mA1 0 0.2 pH on
mA1
pH (table) on mA1 1
Parameter 2 (ORP or rH) on mA1 2
pH on mA2 0
pH (table) on mA2 1
Temperature on mA2 2 Temp. on
mA2
pH PI control on mA2 3
Parameter PI control on mA2 4
*D/R Direct or reverse For rising signal, set 0 0 Reverse
acting PI control for decreasing mA output
For rising signal, set 1
for increasing mA output
31 The choices below appear when ORP was selected in service code 01
ORP *OUTPUT.F Output parameter ORP on mA1 0 0.2 ORP on
ORP (table) in mA1 1 mA1
ORP on mA2 0
ORP (table) on mA2 1
Temperature on mA2 2 Temp on
ORP PI control on mA2 3 mA2
*D/R Direct or reverse For rising signal, set 0 0 Reverse
acting PI control for decreasing mA output
For rising signal, set 1
for increasing mA output
32 *BURN Burn function mA 1 No burnout 0 0.0 No Burn.
mA 1 Burnout downscale 1
mA 1 Burnout upscale 2
mA 2 No burnout 0 No Burn.
mA 2 Burnout downscale 1
mA 2 Burnout upscale 2
33 *RG.mA2 PI range Proportional range for mA control signal
*pH.mA2 Display depends on (use >, ^, ENT keys to adjust value) 1.0 pH
*mV.mA2 parameter selected 2.0 rH
*rH.mA2 in code 31 50 mV
34 *tI.mA2 Integral time 100 sec.
(for PI control)
35 *TABL1 Output table for mA1
*0% Linearisation table for mA1 in 5% steps.
*5% The measured value is set in the main
*10% display using the >, ^, ENT keys, for
... each of the 5% interval steps.
... Where a value is not known, that value may
*90% be skipped, and a linear interpolation will
*100% take place.
36 *TABL2 Output table for mA2
*0% Linearisation table for mA2 in 5% steps.
*5% The measured value is set in the main
*10% display using the >, ^, ENT keys, for
... each of the 5% interval steps.
... Where a value is not known, that value may
*90% be skipped, and a linear interpolation will
*100% take place.
37-39 Not used
