3. Cabling
3-61
TI 32P01J10-01EN
Example of Connection to SWD2D
SWD2D terminal board allows SDV526 modules in both single and dual-redundant
congurations.
SDV526 (Digital Output Modules)
SWD2D
F030615.ai
TM4 TM3
1B 2B 3B 4B NC
NC ALM NC
1A 2A 3A 4A NC NC ALM NC
R2
1B 2B 3B 4B NC
NC ALM NC
1A 2A 3A 4A NC NC ALM NC
R1
TM2 TM1
1B 2B 3B 4B NC
NC ALM NC
1A 2A 3A 4A NC NC ALM NC
L2
1B 2B 3B 4B NC
NC ALM NC
1A 2A 3A 4A NC NC ALM NC
L1
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
POWER
1A 2A 3A 4A
1B 2B 3B 4B
FUSE
250V 1A
FUSE
250V 3.2A
L1
POWER
1A 2A 3A 4A
1B 2B 3B 4B
FUSE
250V 1A
FUSE
250V 3.2A
L2
POWER
1A 2A 3A 4A
1B 2B 3B 4B
FUSE
250V 1A
FUSE
250V 3.2A
R1
POWER
1A 2A 3A 4A
1B 2B 3B 4B
FUSE
250V 1A
FUSE
250V 3.2A
R2
AKB652
Yokogawa
specific
cable
Figure Connecting Digital Output Modules to SWD2D Terminal Board (for Dual-redundant Use)
Nov. 27, 2015-00
