3.3 Connecting Ground Cable
Connect ground cables for the ProSafe-RS as follows:
CAUTION
• Connect the terminal connection type device to the protective conductor terminal.
• Connect a power cable of the plug-in device to a grounded socket. The equipment case is
grounded when the power cable is plugged in.
