3. Cabling
3-45
TI 32P01J10-01EN
3.6 Connecting Signal Cables to I/O Modules
(for FIO)
3.6.1 Combination of I/O Modules and Terminal Blocks
A pressure clamp terminal block or signal cable interface adapter is available for eld wiring, or
MIL cables provided by the user may be used.
SEE
ALSO
For the terminal arrangement of the pressure clamp terminals and terminal board, and the pin arrangement of the
MIL connector, refer to GS 32Q06J10-31E, GS 32S06J10-21E or GS 32S06J10-01E “Field Device Connection
(for ProSafe-RS).”
Dedicated signal cable
Dedicated signal cable connection
Pressure clamp terminal block
Pressure clamp terminal connection
Connector cover for MILcable
MIL cable
I/O module
Dedicated signal cable with prevention
pin of false insertion (option)
Prevention pin of false insertion
Figure Terminals for Field Wiring
Nov. 27, 2015-00
To Next Page
