YOKOGAWA ProSafe-RS User Manual

3. Cabling
3-71
TI 32P01J10-01EN
3.7.3 Base Plate for Barrier
 Base Plate for Barrier Types and Terminal Types
The following table shows relation between Base Plate for Barrier Types and Terminal Types.
Table Base Plate for Barrier Types and Terminal Types
Base plate
model
Su󰀩x code
Field wiring
direction
Terminal type
Terminal
position
S2BN4D
Base Plate for
Barrier (MTL)
-C
Left
Pressure clamp
terminal
On barrier
module
-D
Right
S2BN5D
Base Plate for
Barrier (P+F)
-C
Left
Spring clamp
terminal
On base plate
-D
Right
 Installable Barriers with Base Plate for Barrier
The following table shows Modules installable with Base Plate for Barrier.
Table Modules Installable with Base Plate for Barrier
Base plate model Model of installable barrier
S2BN4D
Base Plate for Barrier (MTL)
Refer to the General Specications (GS).
S2BN5D
Base Plate for Barrier (P+F)
Refer to the General Specications (GS).
 Base Plate for Barrier Terminal Numbers
S2BN4D (Pressure Clamp Terminals)
The S2BN4D Base Plate for Barrier do not have signal terminals because signal terminals are
provided on intrinsic safety barriers.
Information about the terminal numbers of the signal terminals provided on the intrinsic safety
barriers, refer to the manufacture’s catalog.
Nov. 27, 2015-00
