2. Transportation, Storage and Installation
2-49
TI 32P01J10-01EN
Mar. 29, 2019-00
2.5.7 Desktop Equipment
There are SENG (PCs), general-purpose printers, etc. as the devices used on the desks.
When installing any devices on the desks, take care about the following:
• It should provide a level horizontal surface for the PC or printer.
• A work space should be preserved to connect the cables.
• Support rising cables to prevent their weight from being applied to connectors directly. Keep
a space of 100 mm radius or more around the connectors.
• Do not place the desk such as to expose the PC to direct sunlight or high humidity.
2.5.8 Installing Control Network Interface Card
This section describes how to install VI702 Control Network interface card. The card is installed
in a PCI Express slot of an SENG PC to connect it to the Control Network.
SEE
ALSO
• The steps described below are based on general-purpose PC/AT compatible machines. For details, refer to
the manual for the specic PC.
• For the station address setting, refer to the Safety Control Stations (Hardware), IM 32P06C10-01EN or
IM 32Q06C10-31E.
Card Installation Procedure
1. Set the station address for the control bus interface card.
2. Turn o the computer and unplug the power cord for safety.
3. Remove the PC cover.
4. Remove the slot cover.
5. Insert the control bus interface card in the slot. Make certain that the card is properly set in
the slot.
6. Attach the computer cover.
7. Write the station address on a seal (sticker) and attach it to the front of the PC or in another
similarly easy-to-view place.
SEE
ALSO
• For the electrostatic protection, refer to 1.5.2, “Countermeasures against Static Electricity.”
• For the control bus connections, refer to 3.7, “Connecting Bus Cable.”
To Next Page
