No. Product Model Description
6
Communication
module
ALR111-1
Serial communication module (RS-232C, 2-port)
ALR121-1
ALR121-B
ALR121-3
Serial communication module (RS-422/RS-485, 2-port)
ALE111-1
ALE111-3
Ethernet communication module
S2LP131 Fire and gas communication module
7 Wiring check adapter
SCB10
Wiring check adapter for digital input module
8 Power supply bus unit
AEPV7D-6
AEPV7D-F
Power Supply Bus Unit, Vertical Type
AEP7D-6
AEP7D-F
Primary power supply bus unit
9 Terminal Board
A2BM4 Terminal board for analog digital I/O
SEA4D Analog terminal board (Single and Dual-redundant, 16 channels x 2)
SBA4D
Terminal board for Analog: DIN rail mount type
(Single and Dual-redundant, 16 channels x 1)
SBT4D
Terminal board for TC/mV: DIN rail mount type
(Single and Dual-redundant, 16 channels x 1)
SBR4D
Terminal board for RTD input: DIN rail mount type
(Single and Dual-redundant, 16 channels x 1)
SED2D Digital terminal board (Single and Dual-redundant, 4 channels x 4)
SED3D Digital terminal board (Single and Dual-redundant, 8 channels x 4)
SED4D Digital terminal board (Single and Dual-redundant, 16 channels x 2)
SWD2D
Digital terminal board
(Single and Dual-redundant, 100 to 120 V AC, 4 channels x 4)
SBD2D
Terminal board for Digital output: DIN rail mount type
(Single and Dual-redundant, 4 channels x 1, for SDV521)
SBD3D
Terminal board for Digital output: DIN rail mount type
(Single and Dual-redundant, 8 channels x 1, for SDV53)
SBD4D
Terminal board for Digital: DIN rail mount type
(Single and Dual-redundant, 16 channels x 1, for SDV144/SDV541)
S1BB4D Terminal Board for Analog Input, 3-wire: DIN rail mount type
10 Router
AVR10D-
1
Duplexed V net router
AW810D-
6
Wide Area Communication Router
11
Node Interface
Unit
S2NN30D Node Interface Unit (for N-IO)
12 Base Plate
S2BN1D Base Plate with disconnecting terminal (for N-IO, 16 channels)
S2BN4D Base Plate for Barrier (for N-IO, MTL Barrier)
S2BN5D Base Plate for Barrier (for N-IO, P+F Barrier)
13 I/O Module
S2MMM843 Analog Digital I/O Module (16 channels, module isolation)
S2MDV843 Digital I/O Module (16 channels, module isolation)
Oct. 5, 2018-00
