2. Transportation, Storage and Installation
2-27
TI 32P01J10-01EN
The required number of node fans varies depending on the number of nodes to be installed.
Table Number of Nodes to Be Installed and Need to Install Fans
Location No.
(*1)
7 units on one
side
6 units on one
side
5 units on one
side
4 units on one
side
Front
37-42
Node 1
(SSC60-F)
Node 1
(SSC60-F)
Node 1
(SSC60-F)
Node 1
(SSC60-F)
34-35
Fan (SSC60-F) Fan (SSC60-F) Fan (SSC60-F) Fan (SSC60-F)
29-33 Node 2 Node 2 Node 2 Node 2
24-28 Node 3 Node 3 Node 3 Node 3
23 Node Fan 1 Node Fan 1 — —
18-22 Node 4 Node 4 Node 4 Node 4
13-17 Node 5 Node 5 Node 5 —
8-12 Node 6 Node 6 — —
3-7 Node 7 — — —
Rear
38-42 Node 8 Node 8 Node 8 Node 8
36 Node Fan 3 Node Fan 2 Node Fan 2 —
30-34 Node 9 Node 9 Node 9 Node 9
25-29 Node 10 Node 10 Node 10 Node 10
24 Node Fan 3 Node Fan 3 — —
19-23 Node 11 Node 11 Node11 Node 11
14-18 Node 12 Node 12 Node 12 —
9-13 Node 13 Node 13 — —
4-8 Node 14 — — —
—: Not installed
*1: Location numbers correspond to the installation positions in the gure above.
· Fan specications
Door fan (on one side): Maximum air ow rate 210 m
3
/h or more
Node fan: Maximum air ow rate 480 m
3
/h or more
The door vent and roof vent must be larger than the opening area of the door fan.
· I/O module installation restrictions
Refer to and follow the installation restrictions specied in “ NODE UNIT MOUNTING
RESTRICTIONS” in the “ProSafe-RS Outline of I/O Modules” (GS 32Q06K20-31E).
· Detecting a fan failure
It is recommended to monitor the rotation of the fans or the temperature in the cabinet
to detect a fan failure.
