General Instruction Manual
Installation
Transmitter installation
34 / 90
IM 01U10B00-00EN-R, 3rd edition, 2018-07-09
5. Remove the display from housing by pulling forward.
6. Rotate display and push back into housing in the orientation desired.
NOTICE
The display can be removed and replaced by loosening the connector.
