General Instruction Manual
System configuration and operation
Default settings
72 / 90
IM 01U10B00-00EN-R, 3rd edition, 2018-07-09
The following values are only available for the trend display to record data on the mi-
croSD card. Additional information about data recording can be found in the applicable
software instruction manual.
Only use the microSD card included with the Rotamass Total Insight. Functionality of the
device cannot be guaranteed if other cards are used.
Tab.2: Trend display
Abbreviation Measured quantity or identification
MFL Mass flow
DNS Density
TMP Temperature
VFL Volume flow
PRS Pressure
CNC Concentration
NM1 Net mass flow rate 1
NV1 Net volume flow rate 1
PHS Phase shift
FRQ Resonance frequency
DRG Drive gain
DRC Driving current
MBT Transmitter temperature
VSC Viscosity
9.3 Default settings
9.3.1 Setting display language
1. Press [SET] switch for 2 seconds to enter [Operation level].
2. Press [▼] switch 1 time to enter [Operator].
3. Press [SET] switch to enter [Device setup].
4. Press [▼] switch until [Lang] is selected.
5. Press [SET] switch to enter the [Lang] menu.
6. Press [▼] switch repeatedly until the desired language appears.
7. Press [SET] switch to select the desired language.
8. Press [SET] switch to confirm the language selected.
ð Display switches to the next higher menu level.
