YOKOGAWA WT332E - Page 39

2-5
IM WT310E-02EN
Making Preparations for Measurements
1
2
3
4
5
6
7
App
Index
Installation Position
Desktop
Place the instrument in a horizontal position or tilt it on its handle or movable legs. Place the instrument
on a flat, level surface as shown in the figure below.
• WT310E/WT310EH
To use the handle as a stand to tilt the instrument, first check that the handle is fixed in place,
and then position the instrument. To rotate the handle, first pull the handle’s rotary axis out
approximately 2 mm to 3 mm on both the left and right sides of the instrument, and then rotate it
slowly to one of its stop positions.
1
2
3
4
5
6
7
8
1
3
Rotating base
Pull this out approximately 2 mm
to 3 mm, and rotate the handle.
Handle stop positions (We recommend that you use positions 1, 3, 5, and 8. Do not place a heavy load
on this instrument when the handle is in stop position 2 or 4.)
• WT332E/WT333E
Movable legs
WARNING
• When adjusting the WT310E/WT310EH handle, be careful not to injure your hand with the
edges of the handle.
• When you put away the handle or movable legs, be careful not to get your hand caught
between the handle or movable legs and the instrument.
• Handling the movable legs or handle without firmly supporting the instrument can be
dangerous. Please take the following precautions.
• Only handle the movable legs or handle when the instrument is on a stable surface.
• Do not handle the movable legs or handle when the instrument is tilted.
• Do not place the instrument in any position other than those shown in the above figures.
French
AVERTISSEMENT
• Lors du réglage de la poignée WT310E/WT310EH, éviter toute blessure à la main avec les
bords de la poignée.
• Au moment de rabattre la poignée ou les pieds escamotables, éviter de coincer une main
entre la poignée ou les pieds escamotables et l'instrument.
• Pour manipuler les pieds escamotables ou la poignée, toujours soutenir l'instrument
fermement. Prendre les précautions suivantes.
• Ne manipuler les pieds escamotables ou la poignée que lorsque l'instrument est placé
sur une surface stable.
• Ne pas manipuler les pieds escamotables ou la poignée lorsque l'instrument est incliné.
• Ne pas placer l'instrument dans des positions autres celles indiquées ci-dessus. Ne pas
empiler l'instrument.
2.2 Installing the Instrument
