2.12 Connecting to a PC via USB (Installing
WTViewerFreePlus)
When you connect this instrument to a PC, you can save measured data to the PC and change
the settings of this instrument from the PC. In addition, you can use WTViewerFreePlus, which is a
software application supplied with this instrument, to save measured data to the PC and change the
settings of this instrument, without having to create original communication control programs.
WT310E/WT310EH
WT332E/WT333E
PC monitor
Saved data
Setting changes
This instrument can be connected to a PC using the following communication interfaces.
• USB
• GP-IB
• RS-232
• Ethernet
This section explains how to connect this instrument to a PC via USB. To connect to a PC via a
different communication interface, see chapter 4 in the WTViewerFreePlus User’s Manual, IM 760121-
02E.
Connecting this instrument to a PC via USB
Use a USB cable to connect the USB port for PCs (type B connector) on the rear panel of this
instrument to the PC.
USB port
USB port
WT310E/WT310EH
WT332E/WT333E
PC
USB cable
