2-8
IM WT310E-02EN
Connecting the Power Cord
1.
Check that the instrument’s power switch is off.
2.
Connect the power cord plug to the power inlet on the rear panel of the instrument.
3.
Connect the other end of the cord to an outlet that meets the following conditions. Use a
grounded three-prong outlet.
Item Specification
Rated supply voltage 100 VAC to 120 VAC, 200 VAC to 240 VAC
Permitted supply voltage range 90 VAC to 132 VAC, 180 VAC to 264 VAC
Rated power supply frequency 50/60 Hz
Permitted supply frequency range 48 Hz to 63 Hz
Maximum power consumption WT310E/WT310EH: 50 VA, WT332E/WT333E: 70 VA
* This instrument can use a 100 V or a 200 V power supply. The maximum rated voltage differs according
to the type of power cord. Check that the voltage supplied to the instrument is less than or equal to the
maximum rated voltage of the power cord that you will be using before use.
WT310E/WT310EH WT332E/WT333E
Three-prong outlet
2.3 Connecting the Power Supply
To Next Page
