Connecting to the WT310E/WT310EH
In the wiring examples that follow, the WT310E/WT310EH input elements, voltage input terminals, and
current input terminals are simplified as shown in the following figure.
WT310E/WT310EH
I
C
±
Input element
C
±
V
±
U
V
±
The voltage input terminals
and current input terminals
are labeled as U and I,
respectively.
Voltage input
terminals
Current input
terminals
V: VOLTAGE terminal
C: CURRENT terminal
CAUTION
The thick lines on the wiring diagrams are the parts where the current flows. Use wires that
are suitable for the current levels.
French
ATTENTION
Les lignes épaisses sur les schémas de câblage illustrent l’acheminement du courant. Utiliser
des fils qui conviennent aux niveaux de courant.
2.9 Wiring the Circuit under Measurement for Direct Input
